Casio CELVIANO AP-270 Manual

Receive Receipt is handled, in combination with the following Note On/Off message, as the lower
seven bits of 14-bit Velocity. For information about the relationship between the Note On/Off message
and High Resolution Velocity Prefix message, see ”Instrument Velocity Resolution” at the beginning of
part II.
5.19 Reverb Send (5BH)
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when Music Library play (etc.) is operated.
Receive Receipt changes the reverb send of the corresponding part.
5.20 Chorus Send (5DH)
Message Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when Music Library play (etc.) is operated.
Receive Receipt changes the chorus send of the corresponding part.
5.21 NRPN (62H,63H)
Message Format: BnH 62H llH (LSB)
BnH 63H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
5.21.1 Assignable Functions to NRPN
This Instrument does not assign any parameters to NRPN.
5.22 RPN (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
12

Casio CELVIANO AP-270 Specifications

General

Touch Response	3 sensitivity levels, Off
Tones	22 built-in tones
Pedals	3 pedals (damper, soft, sostenuto)
Speakers	12cm x 2
Amplifiers	8W + 8W
USB Port	Type B
Power Consumption	18W
Keyboard	88 keys, Tri-sensor Scaled Hammer Action Keyboard II
Sound Source	AiR Sound Source
Digital Effects	Reverb (4 types), Chorus (4 types), Brilliance, DSP
Songs	60 Music Library tunes, 10 User Songs
Recording	2 tracks, 1 song
Lesson Function	Part ON/OFF
Metronome	0 to 9 beats, tempo range: 20 to 255
Key Transpose	-12 to 0 to +12 semitones
Tuning Control	A4 = 415.5 to 440.0 to 465.9 Hz
Headphones	2
MIDI	Yes
Power Supply	AC adaptor: AD-A12150LW
Included Accessories	AC Adaptor, Music Stand
Polyphony	192 notes
