21-4 Before Performing a Data Communication
Operation
In the Main Menu, select the LINK icon and enter the LINK Mode. The following
data communication main menu appears on the display.
P. 408 Image Set: .......... Indicates the status of the graphic image send features.
Off: Graphic images not sent.
Monochrome: Pressing M sends graphic images in
monochrome.
Color: Pressing M sends graphic images in color.
Do not select "Color" for Image Set to
send data to a Label Printer.
On: Pressing M sends graphic images in
monochrome.
• {TRAN}/{RECV} ... menu of {send settings}/{receive settings}
• {IMGE} ... {menu of graphic image transfer settings}
Communication parameters are fixed at the following settings.
•Speed (BPS): 9600 bits per second
•Parity (PARITY): NONE
CFX
fx-9750G
PLUS
