Configuring Digital Piano Settings
EN-55
English
■ MIDI Screen
Use this screen to configure MIDI settings.
For information about MIDI channels assigned to each port, see “Part and MIDI Channel Assignments” (page A-17).
■ MEDIA Screen
Use this screen to save data to a USB flash drive inserted in the Digital Piano and to import data from a USB flash
drive to Digital Piano memory. For more information, see “USB Flash Drive” (page EN-56).
Item Description Setting
Keyboard Channel Selects the channel for sending keyboard play MIDI data to an external
device (keyboard channel).
01 to 16
Accomp Out Turn on this setting to send MIDI data corresponding to Auto
Accompaniment to an external device.
Off, On
Chord Judge Select whether Chord input should be performed when a MIDI note on
message to the Auto Accompaniment chord keyboard is received.
Off, On
Hi-Res Vel Out Turns high-resolution velocity MIDI out on or off. Off, On
Local Control Selecting “Off” for Local Control cuts off the Digital Piano’s sound source, so
no sound is produced by the Digital Piano when keys are pressed.
Off, On
MIDI Out/Thru Specifies either Out or Thru as the MIDI OUT terminal function. Out, Thru
MIDI In Port Select the port to be used for input from the MIDI In. A, B, C
PX360-ES-1A.indd 57 2015/04/24 12:46:50
To Next Page
