EN-11
Controlling the Keyboard Sounds
• Two tones, one for the left range and one for the right
range of the keyboard (page EN-12)
This configuration uses the UPPER 1 part and LOWER part
(Layer: Off, Split: On).
• Three tones, two layered tones for the right range and
one tone for the left range of the keyboard (page EN-12)
This configuration uses the UPPER 1 part, UPPER 2 part,
and LOWER part (Layer: On, Split: On).
• Changing the tone setting affects the UPPER 2 part when
Layer is turned on, and the LOWER part when Split is
turned on.
• To change the currently part affected by a tone change,
press and then release bl TONE, and then long press
bl TONE again. This will cause the pointer () next to the
part indicator on the display to move. Repeat long pressing
of the bl TONE button until the pointer is next to the part
you want.
• When you have multiple DSP tones selected, the DSP tone
effects assigned to the UPPER 2 and LOWER parts may
become disabled.
• Check to make sure that the U2 (Layer) and L (split)
indicators are not shown on the display before starting this
procedure. If either indicator is displayed, press cp LAYER
and/or co SPLIT so they are not displayed.
1.
Select the first tone you want to use.
Press bl TONE and then use the ct number keys, and
the dk [–] and [+] keys to select the tone you want.
Example: 024 ELEC.PIANO 1
2.
Press cp LAYER.
3.
Use the ct number keys, and the dk [–] and [+]
keys to select the second tone you want.
Example: 187 STRINGS
4.
Play something on the keyboard.
Both tones sound at the same time.
• Pressing cp LAYER again will turn layer off.
LOWER UPPER 1
LOWER
UPPER 1
UPPER 2
To layer two tones
E . P i a n o 1
Lights
S t r i n
g
s
CTX700-ES-1A.indd 13 2017/10/05 11:03:15
