Casio CTK-2000 Service Manual And Parts List

– 18 –
1 CTK-2000_DI
2 CTK-2000_CHINA
3 CTK-2000_EU
4 CTK-2000_UK
5 CTK-2000_US
1 2 3 4 5
Main PCB
N 1 10304685
PCB ASSY/MDA1 TK-RJM508605*001
1 1 1 1 1 CU A
D3 10276977 CHIP DIODE L1SS400T1G 1 1 1 1 1 AA X
D2 79114195 DIODE UDZSTE-175.6B 1 1 1 1 1 AA X
IC6 10211950 I.C NJM2068M-D(TE1) 1 1 1 1 1 AC C
IC4 10269340 IC XC6403FY51PR 1 1 1 1 1 AE X
L9 10193074 COIL DLW21HN181SQ2L 1 1 1 1 1 AC X
L11 10238668 CHIP BEAD CORE EBMS160808A102 1 1 1 1 1 AA X
Sub PCB
N 2 10304686
PCB ASSY/PSA1 TK-RJM508607*001
1 1 1 1 1 CM B
J104 10206815 CONNECTOR JY-6314*01-030 1 1 1 1 1 AA C PEDAL JACK
L103,105 10231919 COIL RB53-856396NP 2 2 2 2 2 AA X
L102,104 10231920 COIL RB53-856397NP 2 2 2 2 2 AA X
J102 10088189 DC JACK DS-240A2-383V4H 1 1 1 1 1 AC C
D103,104,106,107 10276977 CHIP DIODE L1SS400T1G 4 4 4 4 4 AA X
D101,102 10210387 DIODE RSX101VA-30TR 2 2 2 2 2 AA X
IC2,IC3,IC4 10211950 I.C NJM2068M-D(TE1) 3 3 3 3 3 AC X
Q101 22592702 CHIP TRANSISTOR 2SB1188T100R 1 1 1 1 1 AB X
Q102 69300298 CHIP TRANSISTOR 2SC4081T106R 1 1 1 1 1 AA X
Console PCBs
N 3 10304684
PCB ASSY/CNA1 TK-RJM508599*001
1 1 1 1 1 CO C
IC401 10222381 LSI ST7066U-0A-QG 1 1 1 1 1 AU C
TH401 10138692 THERMISTOR NCP18XH103J03RB 1 1 1 1 1 AA X
VR401 69304870 VOLUME EVND8AA03B53 1 1 1 1 1 AA X
D401-408 10276977 CHIP DIODE L1SS400T1G 8 8 8 8 8 AA X
Keyboard PCB
s
N 4 10304689
PCB UNIT/RUBBER TK-RJM508597*001
1 1 1 1 1 CB C
N 5 10304690
PCB ASSY/KYA K-RJM508609*001
1 1 1 1 1 CB C
Keyboard Uni
t
6 10163902
RUBBER/CONTACT/CB RJM503854-001
4 4 4 4 4 AD B
7 10163903
RUBBER/CONTACT/CS RJM503855-001
1 1 1 1 1 AG B
N 8 10304687
WHITE KEY/CB TK-RJM507243*002
4 4 4 4 4 AW C
N 9 10304688
WHITE KEY/CS TK-RJM507244*002
1 1 1 1 1 AX C
10 10274032 BLACK KEY/10P RJM506595-001V02 2 2 2 2 2 AL C
11 10274160 BLACK KEY/5P RJM506595-002V02 1 1 1 1 1 AE C
Case Uni
t
N 12 10301466 PLATE/DISPLAY RJM508541-001V01 1 1 1 1 1 AG C
13 10199714 KNOB/SLIDE RJM503803-002V01 2 2 2 2 2 AB C
14 69095890 CONTACT/SLIDE CSB-12D 2 2 2 2 2 AC C
N 15 10301465 CONNECTOR RJM508539-001V01 2 2 2 2 2 AD C
N 16 10301473 LCD TY-11151N 1 1 1 1 1 AZ C
N 17 10301453 RUBBER KEY/A RJM508524-001V01 1 1 1 1 1 AH C
N 18 10301454 RUBBER KEY/B RJM508525-001V01 1 1 1 1 1 AJ C
N 19 10301455 RUBBER KEY/C RJM508526-001V01 1 1 1 1 1 AH C
N 20 10301456 RUBBER KEY/D RJM508527-001V01 1 1 1 1 1 AH C
N 21 10301457 RUBBER KEY/E RJM508528-001V01 1 1 1 1 1 AL C
N 22 10301458 RUBBER KEY/F RJM508529-001V01 1 1 1 1 1 AJ C
23 10264808 SPEAKER C10J01A 2 2 2 2 2 AJ C
24 10243428
COVER ASSY/BATTERY TK-M340884*020
1 1 1 1 1 BE C
25 10310585 PCB ASSY/PSA2 TK-RJM509016*001 1 1 1 1 1 BV C
QTY
Price
Code
N Item Parts No. Parts Name Specification R Remarks

Casio CTK-2000 Specifications

General

MIDI-keyboard number of keys	61 keys
Interface	USB
DC-in jack	Yes
Dimensions (WxDxH)	949 x 354 x 112 mm
Power requirements	9V DC, 7.7W
Compatible operating systems	- Windows XP/Vista - Mac OS X 10.3

Weight and Dimensions

Weight	3800 g
