Casio CTK-2000 Service Manual And Parts List

– 13 –
DIAGNOSTIC PROGRAM

Initial Setting
1. Connect the AC adaptor.
2. "Main" volume: MAX

How to start diagnostic program
1. Press and hold the "0", "1" and "2" buttons.
2. Press the "POWER" button.
3. The massage "TESTMODE" is appears on LCD.
4. Release the "0", "1" and "2" buttons.

Diagnostic program
Message on LCD
1. Button check

Press "1" button.
1:SW

Press the button in the order indicated in the illustration below.
The button number will be displayed on the LCD.
Example) SW00 + (the button number shown in the illustration)
Press "SETTING" button.
1:SW 001 F
If the switch function is OK: You will hear the OK sound signal and the button number will be displayed.
If the switch function is NG or switches were pressed in a wrong order: You will hear the NG sound signal
and the button number will be displayed.

Press the "3" button the last.
1:SW OK!
1F
1E
1D
1C
03
04
05
06
07
0E
09
08
0D
0A
0B
SW OK! 10 11 12
161B 14 15
191A 17 18
02 01 00
0F
0C

Press "0" to end the LCD Check.
TESTMODE
TEST 1-9

Casio CTK-2000 Specifications

General

MIDI-keyboard number of keys	61 keys
Interface	USB
DC-in jack	Yes
Dimensions (WxDxH)	949 x 354 x 112 mm
Power requirements	9V DC, 7.7W
Compatible operating systems	- Windows XP/Vista - Mac OS X 10.3

Weight and Dimensions

Weight	3800 g
