CTK-4200
– 11 –
DISASSEMBLY
A. REMOVE THE PANEL UNITS
Main panel unit Right panel unitLeft panel unit
A-1. Undo 17 or seven screws on the bottom surface of the main unit.
NOTE: To remove only the main panel unit, undo seven screws indicated with red circles in the
illustration below.
