CTK-4200
– 20 –
F. REMOVE THE M802-KYA1/KYA2 PCBs (KEYBOARD PCB)
M802-KYA1 PCB M802-KYA2 PCB
F-1. Disengage the hooks and then remove the M802-KYA1/KYA2 PCBs.
