Item Code No. Parts Name Specification Q R
Main PCB
1
6926 6310 PCB ASSY/M450-MA1M M240821*1 1 B
2
6926 6320 PCB ASSY/M450-MA2M M140731*1 1 B
D1
2390 1820 DIODE/CHIP 1SS355TE-17 1 C
D101
2390 3021 DIODE SRT14 1 C
D102
2390 3018 DIODE 1T2 1 C
D103,D104
D106 - D114
2390 1344 DIODE 1SS133T-77-T 11 C
D105
2360 1939 DIODE MTZJ5.1CT-77-T 1 C
IC1
2012 1883 IC/MOS RN5VD40AA-TR 1 B
IC101
2114 2891 IC/LINEAR LA4598 1 B
J101
3501 7049 JACK/POWER HEC2305-01-330 1 C
J102
3612 0665 JACK/PHONE YKB21-5006 1 C
L102
3841 2051 INDUCTOR LAN02TA100J 1 C
LED101
2320 3146 LED TLR124 1 C
LSI1
2012 5603 LSI MSM6755B-17 1 A
LSI2
2012 5937 LSI LC372100PM-H78TE-L 1 A
LSI3
2012 5935 LSI KS0066U-10B 1 A
Q1 / Q3
2252 1239 TRANSISTOR 2SC4081T106Q 2 B
Q101
2200 2481 TRANSISTOR 2SA854SR-TP-T 1 B
Q102, Q104 - Q107
2220 1409 TRANSISTOR 2SC1740SR-TP-T 5 B
Q103
2250 1591 TRANSISTOR 2SB1237TV2R 1 B
Q2
2250 1162 TRANSISTOR 2SA1576AT106R 1 B
VR1
2775 0994 VOLUME/SEMI-FIXED EVND8AA03B53 1 C
X1
2590 2741 OSCILLATOR/CERAMIC CSACV20.00MXJ040-TC 1 C
Console PCB ass'y
3
6925 1310 PCB ASSY/KY M140402*4 1 B
D701 - D725
2301 0101 DIODE 1SS2473 25 C
D731 - D766
2301 0101 DIODE 1SS2473 36 C
Mechanical Parts
4 6926 6790 PANEL/DISPLAY M340785-1 1 C
5
6909 5890 KNOB CSB-12D 1 C
6
3831 0665 SPEAKER 10G42AFA 2 B
7
3335 6677 LCD CA480-TS 1 A
8
6922 2740 KEY SET/BLACK 10-KEY M111726-1 2 A
9
6922 2750 KEY SET/BLACK 5-KEY M111726-2 1 A
10
6922 3990 RUBBER/CONTACT M111764-1 1 B
11
6922 4000 RUBBER/CONTACT M111765-1 1 B
12
6921 5030 KNOB/SLIDE M311859-1 1 C
13
6922 2720 KEY SET/LT-CB WHITE M312118*1 4 A
14
6922 2730 KEY SET/LT-CB WHITE M312118*2 1 A
15
6926 6750 RUBBER/BUTTON M340417-4 1 C
16
6926 6760 RUBBER/BUTTON M340418-3 1 C
17
6925 9840 COVER/BATTERY M340485*2 1 C
18
6926 6770 RUBBER/BUTTON M340783-1 1 C
19
6926 6780 INTERCONNECTOR M440581-1 2 C
Accessary
6916 7880 STAND/MUSIC M310827-1 1 C
Notes: Q – Quantity per unit
R – Rank
— 17 —
