Casio CTK-496 Service Manual

PARTS PRICE LIST
CTK-496
N Item Parts code Parts name Specification Q
Price
Code
R Remarks
Main PCB
N 1 1016 3666 PCB ASSY/MAA TK-RJM503927*001
1
CV A
N
D225
1010 7268
LED 1154HD-B5/7-90 1
AA C
J204
1008 1222
CONNECTOR HDC-052S-02 1
AF C
J203,205
6932 5081
CONNECTOR JY-6314-01-030 2
AB C
J201
6932 5082
CONNECTOR JY-6316-01-070 1
AD C
L201
1005 7360
COIL R2318-RB53-856396 1
BB X
L202
1005 6228
COIL R2318-RB53-856397 1
AB X
IC203
6932 3623
PHOTO COUPLER PC900V0NSZX 1
AF X
VR201
2775 0994
VARIABLE R EVN-D8AA03B53 1
AA C
Q302
1007 9925
TRANSISTOR KTA1267GR-AT 1
AA C
Q202,205
1007 9927
TRANSISTOR KTC3199GR-AT 2
AA C
Q304
1013 2122
TRANSISTOR KTD863GR-AT 1
AA C
Keyboard PCB
N 2 1016 3667 PCB ASSY/KYA TK-RJM503929*001
1
BX C
N
D701-761
1010 8141
DIODE 1SS133TP
61 AA X
Keyboard unit
3
6922 2720 KET SET/WHITE M312118*1 4
AP C
4
6922 2730 KEY SET/WHITE M312118*2 1
AR C
5 6922 2740 KEY SET/BLACK 10P M111726-1
2
AQ C
6 6922 2750 KEY SET/BLACK 5P M111726-2
1
AH C
N 7 1016 3902 RUBBER/KEY RJM503854-001V01
4
AD B
N 8 1016 3903 RUBBER/KEY RJM503855-001V01
1
AF B
Panel unit
N 9 1016 3946 PLATE/DISPLAY RJM503799-001V01
1
AE C
N 10 1016 3934 RUBBER/KEY/A RJM503792-001V01
1
AB C
N 11 1016 3931 RUBBER/KEY/B RJM503793-001V01
1
AA C
N 12 1016 3932 RUBBER/KEY/C RJM503794-001V01
1
AB C
N 13 1016 3942 RUBBER/KEY/D RJM503795-001V01
1
AA C
N 14 1016 3943 RUBBER/KEY/E RJM503796-001V01
1
AB C
N 15 1016 3944 RUBBER/KEY/F RJM503797-001V01
1
AC C
N 16 1016 3945 RUBBER/KEY/G RJM503798-001V01
1
AE C
N 17 1016 1407 KNOB/SLIDE RJM503803-001V01
1
AA C
18 6927 0510
CONTACT/SLIDE CSB-08D 1
AD B
19 3831 1043
SPEAKER S10JA13B 2
BE C
N 20 1016 3669 COVER ASSY/BATTERY TK-M340884*014
1
AU B
21 1007 8118
CONNECTOR M440863-003V01 2
AB C
N 22 1016 1408
KNOB/ROTARY
RJM503816-001V01
1
AA C
N 23 1016 9838
LCD TR3573N 1
AU C
24 6927 1080 TERMINAL/BATTERY (+) M440112-1
1
AB X
25 1000 8078 TERMINAL/BATTERY (-) M440002A-1
1
AA X
26 6927 1060 TERMINAL/BATTERY M440676-1
2
AA X
27 6927 1070 TERMINAL/BATTERY M440677-1
3
AA X
Refurbish
N R-1 1016 3933 CASE/UPPER RJM503790-001V01
1
BR C
N R-2 1016 3668 CASE ASSY/MIDDLE TK-RJM503916*001
1
CN C Except US
N R-2 1016 4732 CASE ASSY/MIDDLE TK-RJM503916*002
1
CN C For US
N R-3 1016 3935 PLATE/LOWER/A RJM503801-001V01
1
AE C
N R-4 1016 3936 PLATE/LOWER/B RJM503802-001V01
2
AB C
R-5 6922 6920 RUBBER/FOOT M41361-6
5
AA C
Accessories
- 6920 8690 STAND/MUSIC M311760-1 1 AL C
- 1008 3548 BATTERY R6UW/2STA 3 AC C Only DI
Notes:
N
- New parts
Q
-Quantity used per unit
- 16 -

Casio CTK-496 Specifications

General

MIDI-keyboard number of keys	61 keys
Interface	USB
DC-in jack	Yes
Dimensions (WxDxH)	956 x 354 x 132 mm
Power requirements	9 V DC

Weight and Dimensions

Weight	3800 g
