Casio CTK-810 Service Manual

– 16 –
1 CTK-810_DI
2 CTK-810_EU
3 CTK-810_UK
4 CTK-810_US
1234
Main PCB
N 1 10271791 PCB ASSY/MAIN TK-RJM507852*001 1111 CXA
N IC1 10269340 IC XC6403FY51PR 1111 AEC
N IC2 10269339 IC XC6216B332PR 1111 AFC
IC13 10123002 IC TC74VHC174FT(EL) 1111 ADC
IC7 10197555 IC TC7SZ14FU(TE85L.F) 1111 AEC
IC8 10197809 IC TC7WH123FU(TE12L.F 1111 AEC
N IC10 10261872 LSI CY62126EV30LL45ZST 1111 ASC
N IC12 10269429 LSI MR27T6402L0GKTN03D 1111 BFC
D1-3 10009218 DIODE 1SS400TE61 3333 AAC
IC4,IC6 10216444 IC TC7SET04FU(TE85L.F 2222 ADC
IC11 10179619 IC TC7SZ04FU(TE85L.F) 1111 AAC
IC9 10197554 IC TC7SZ126FU(TE85L.F 1111 AEC
N L10 10193074 COIL DLW21HN181SQ2L 1111 ACC
N
L1,3,4,5,
6,9,11,12
10238668 CHIP BEAD CORE EBMS160808A102 8888 AAC
N L2 10238669 FERRITE BEAD EBMS201209A102 1111 AAC
Q3 10153685 FET 2SJ346(TE85L.F) 1111 AAC
Q1,Q2 10202670 TRANSISTOR KTA2014-GR-RTK/P 2222 AAC
N CN6 10236622 CONNECTOR USB-4FBRS30NB2 1111 ACC
Sub PCB
N 2 10271790 PCB ASSY/PSA1 TK-RJM507856*001 1111 BQB
IC301 10206337 IC LA4635A-E 1111 ANC
IC302 10206677 IC NJM2068D-D 1111 AHC
J301 10209462 JACK DJ-0702O*015 1111 AAC
J303 10206815 CONNECTOR JY-6314*01-030 1111 AAC
J302 10213695 JACK JY-6316*01-070 1111 ACC
L302 10206672 COIL R2318-RB53856396NP 1111 AAC
L301,303 10206680 COIL R2318-RB53856397NP 2222 AAC
Q305 10206676 TRANSISTOR KTC2026-Y-U/P 1111 ABC
Console PCBs
N 3 10271794 PCB ASSY/CNA TK-RJM507863*001 1111 CAC
D401 10206836 LED 1154HD-B5/5.5-90 1111 AAC
D406 10116453 LED 1154HD-B5/6.5-90 1111 ABC
D404,405 10123009 LED 1154HD-B5/8-90 2222 AAC
N IC401 10222381 LSI ST7066U-0A-QG 1111 AUC
IC402 10159709 LSI UPD65881GK-1019ETA 1111 ATC
N TH401 10236621 THERMISTOR TTC05103KIY 1111 AAX
VR402 69304870 SEMI FIXED VOL EVND8AA03B53 1111 AAX
VR401 10123103 VARIABLE RESISTOR RK09K12C0D1B 1111 AHC
X401 10093909 CERAMIC OSCILLATOR CSBLA1M00J58-B0 1111 ACC
N
Keyboard PCBs
N 4 10271796 PCB UNIT/RUBBER TK-RJM507659*001 1111 BUC
N 5 10271797 PCB ASSY/KEY TK-RJM507866*001 1111 BKC
D801-
D922
23153132 DIODE 1SS133T-77 122 122 122 122 AA X
Q'TY
RemarksRSpecification
Price
Code
Parts Name
Parts
No.
ItemN

Casio CTK-810 Specifications

General

MIDI-keyboard number of keys	61 keys
Mac compatibility	Yes
Dimensions (WxDxH)	945 x 373 x 131 mm
Power requirements	9V DC, 7.7W
Compatible operating systems	- Windows XP/Vista - Mac OS X 10.3
Interface	USB

Weight and Dimensions

Weight	4800 g
