Casio CTK-810 Service Manual

– 17 –
1 CTK-810_DI
2 CTK-810_EU
3 CTK-810_UK
4 CTK-810_US
1234
Keyboard Unit
N 6 10269451 RUBBER/CONTACT/CB RJM507656-001V01 4444 AFB
N 7 10270393 RUBBER/CONTACT/CS RJM507657-001V01 1111 AHB
8 10249864 WHITE KEY/CB TK-RJM507243*001 4444 AQC
9 10249865 WHITE KEY/CS TK-RJM507244*001 1111 ATC
N 10 10274032 BLACK KEY/10P RJM506595-001V02 2222 ALC
11 10247548 BLACK KEY5P RJM506595-002V01 1111 AEC
Case Unit
N 12 10269447 REFRECTOR RJM507738-001V01 1111 ADC
13 10116376 LED SLR343BBT3F 2222 AJC
N 14 10270495 PLATE/DISPLAY RJM507717-001V01 1111 AJC
N 15 10270392 KNOB/SLIDE RJM503803-006V01 1111 AAC
N 16 10270487 KNOB/ROTARY RJM502503-019V02 1111 AAC
N 17 10270398 RUBBER KEY/A RJM507682-001V01 1111 AAC
N 18 10270399 RUBBER KEY/B RJM507683-001V01 1111 ACC
N 19 10270400 RUBBER KEY/B RJM507683-002V01 1111 ACC
N 20 10270401 RUBBER KEY/C RJM507684-001V01 1111 AAC
N 21 10270402 RUBBER KEY/D RJM507685-001V01 1111 AEC
N 22 10270403 RUBBER KEY/E RJM507686-001V01 1111 AEC
N 23 10270404 RUBBER KEY/F RJM507687-001V01 1111 AAC
N 24 10270405 RUBBER KEY/G RJM507688-001V01 1111 AGC
N 25 10270406 RUBBER KEY/H RJM507697-001V01 1111 AGC
N 26 10270407 RUBBER KEY/J RJM507698-001V01 1111 AAC
27 69270510 SWITCH/SLIDE KNOB CSB-08D 1111 ADC
N 28 10272002 LCD TR6800N 1111 AYC
N 29 10199879 PLATE/BL RJM505456-001V01 1111 AHC
N 30 10199881 TOP PIECE RJM505457-001V01 1111 AAC
N 31 10199880 FILM RJM505454-001V01 1111 AAC
N 32 10206683 CONNECTOR RJM506034-001V01 2222 AEC
33 10037738 SPONGE M441167-1 2222 AAC
N 34 10272063 SPEAKER C12J03 2222 APC
35 69271080 TERMINAL/BATTERY(+) M440112-1 1111 ABC
36 10008078 TERMINAL/BATTERY(-) M440002A-1 1111 AAC
N 37 10271789 COVER ASSY/BATTERY TK-M340884*024 1111 AFC
38 69271060 TERMINAL/BATTERY M440676-1 2222 C
39 69271070 TERMINAL/BATTERY M440677-1 3333 C
Accessories
- 10107083 STAND/MUSIC M141071-5 1111 AWC
N - 10269397 CD ROM USB12CDROMWL1F 1111 AGC
Refurbish
N R-1 10271792 CASE ASSY/UPPER TK-RJM507637*001 1111 CI C
N R-2 10271795 CASE ASSY/MIDDLE TK-RJM507833*001 1111 CI C
N R-3 10270498 PLATE/LOWER RJM507740-001V01 1111 AQC
Specification
Q'TY
R Remarks
Price
Code
NItem
Parts
No.
Parts Name

Casio CTK-810 Specifications

General

MIDI-keyboard number of keys	61 keys
Mac compatibility	Yes
Dimensions (WxDxH)	945 x 373 x 131 mm
Power requirements	9V DC, 7.7W
Compatible operating systems	- Windows XP/Vista - Mac OS X 10.3
Interface	USB

Weight and Dimensions

Weight	4800 g
