*1 See terminal layout

Back (with the screen underneath) Bottom (with the screen on top)

Figure 2-1 Terminal Layout

Table 2-2 Terminal Table

Terminal Name Function Direction

1 V BUS USB power supply IN/OUT

2 USB_ID USB host/client switch IN

3 D- USB D- IN/OUT

4 D+ USB D+ IN/OUT

5 V CRADLE Unit power supply -

6 GND GND -
