E-20
Handling microSD Cards
The Handheld Terminal supports microSD card.
Since the microSD card slot is located inside the battery compartment, fi rst remove the
batteries when installing or removing a microSD card.
Refer to pages 17 to 18 for information on “Loading and Removing the Main Batteries”.
Install (or remove) a microSD card according to the procedure described below.
Installing
1. Make sure that the power on the terminal has been switched off. If the power is still
on, press the power key to switch off.
2. Remove the batteries.
3. Open the microSD card cover.
4. Lay the card fl at with the front (the side with the text) upwards so that it will slide
into the slot at the rear and then push the card into the slot.
Push the card fi rmly into the slot until it locks into place.
Do not try to insert the card on an angle.
5. Close the microSD card cover and install the batteries.
•
•
To Next Page
