Casio EG-5 - Electrical Parts List

ELECTRICAL PARTS LIST
N Item Code No. Part Name Specification Q
FOB Japan
N.R. Yen
Unit Price
R
PCB ASS'Y M370-MA123M
N 1 6922 9140 PCB Ass'y M370-MA123M M140005*1 1 B
D21 2390 0371 Diode DSK10B-BT-T 1 B
D22 2310 7813 Zener Diode RD10ESB3-T1-T 1 A
N D23 2360 2408 Zener Diode RD3.0ESB1-T1-T 1 B
IC11, IC12 2114 1799 IC M5218APR 2 B
IC13 2114 0070 IC LA4127 1 A
IC21 2114 2632 IC LA4525 1 A
J21, J22 3612 0711 Mini Jack YKB21-5101 2 A
J23 3612 0665 Phone Jack YKB21-5006 1 A
J24 3501 7049 DC Jack HEC2305-01-330 1 A
N S21 3412 1407 Slide Switch HSW3022-01-040 1 A
T22, T22 2220 1409 Transistor 2SC1740SR-TP-T 2 B
T23 2253 0420 Transistor 2SD1468SR,S-TP-T 1 B
T24 2253 0357 Transistor 2SD2008Q,R-T105-T 1 A
N VR11 2765 1701 Volume EVJ06VFA3B14 1 A
VR13 2760 2177 Semi-Fixed Resister V8K4-11B10K 1 C
N VR31 2765 1631 Volume EVLHFKA05B23 1 A
VR32 2765 0049 Semi-Fixed Resister V8K4-11B5K 1 C
JA 3719 4361 Ribbon Cable M370A DF5H08155-8000M 1 C
JB 3719 4368 Ribbon Cable M370B DF5H07120-80008000 1 C
JC 3719 4375 Ribbon Cable M370C DF5H05215-80008000 1 C
JF 3719 4389 Ribbon Cable M370F DF5H06075-8000M 1 C
PV 3749 4382 Ribbon Cable M370H DF0H02120-80258025 1 C
PCB ASS'Y M370-MA4M
N 2 6922 9150 PCB Ass'y M370-MA4M M140006*1 1 B
DI41 2390 1344 Diode 1SS133T-77-T 1 C
N IC41 2114 3500 IC TA8142AP 1 A
IC42 2114 1799 IC M5218APR 1 B
N L41 3841 1344 Bias Coil MS-102-31 1 B
N S41 3412 1337 Slide Switch SSCJ24S-1-1 1 A
T41~T46 2220 1409 Transistor 2SC1740SR-TP-T 6 B
PCB ASS'Y M370-CN1M
N 3 6922 9170 PCB Ass'y M370-CN1M M140007*1 1 B
DI505, DI507
2390 1344 Diode 1SS133T-77-T 6 C
DI504 2390 1323 Diode RB100A-T32-T 1 C
DI506, DI508 2390 1967 Diode RB441QT-77 2 C
DI510 2360 1631 Zener Diode RD5.6ESB1-T1-T 1 B
IC51~IC53 2114 1799 IC M5218APR 3 B
LED51, LED52 2370 0112 LED LN28RPX-(TT8) 2 C
N S51 3412 1400 Tact Switch EVQ QJJ 05Q 1 B
T51~T53 2220 1409 Transistor 2SC1740SR-TP-T 3 B
T54~T56 2240 1149 FET 2SK105E-T 3 B
N VR51 2765 1652 Slide Volume EWA KFEC10BF5 1 A
N VR52 2765 1645 Slide Volume EWA KFEC10B23 1 A
N VR53 2765 1638 Slide Volume EWA KA0C10B23 1 A
N JE 3719 4396 Ribbon Cable M370E DF5H08110-8000M 1 C
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 15 —
