– 10 –
Selection Meaning
ALL All data from Program to Equation
Program Program data
Editor File names and file data
Function Memory Function memory contents
Matrix Matrix memory contents
Statistics Single-variable and paired-variable statistical data
Variable Memory Value memory and extended memory contents
Range Graph range parameters
Factor Factor function zoom ratios
Table Table & Graph function data
Graph Function Graph functions
Dynamic Graph Dynamic Graph function data
Equation Equation coefficients
Back Up All memory contents, including mode settings
TRANSMIT DATA
ALL
Program
Editor
Function Memory
Matrix
Statistics
Variable Memory
RECEIVE DATA
ALL
Program
Editor
Function Memory
Matrix
Statistics
Variable Memory
Pointer Indicates more below
About the Data Type Selection Screen
Whenever you press
F1
(TRN) to send data or
F2
(RCV) to receive data, a data type selection screen appears
on the display.
Send Unit Receive Unit
F1
(TRN)
(RCV)
The following table describes what each of these items means. You will learn later how to make a selection
using these screens.
Parameter Settings
EVEN
PARITY ODD
NONE
1200
2400
4800
9600
Speed (BPS)
Note
• If the selections you make on the send unit and receive unit do not match, a TRANSMIT ERROR will be
generated on the sender and a RECEIVE ERROR will be generated on the receiver.
5-3. Setting Communications Parameters
Before you can perform data communications, you must first set up cartain hardware parameters to make sure
that the two units are able to understand each other. The parameters of the sender and the receiver must be
identical for them to be able to communicate correctly. There are two hardware parameters that you can set.
To Next Page
