Casio FX-9700GH Service Manual & Parts List

FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
70 6408 0150 Tape A-L370 A413596-1
2
20 X
72 6403 9331 Tape C-L170 A413108A-1
2
10 X
73 6407 9930 Flat screw A-L370 A310044-41
1
50 C
75 6408 0190 Tape B-L370 A413639-1
1
20 X
77 6405 9110 Adhesive tape C-L373 A412118A-2
2
20 C
79 6408 0210 PC joiner L370 A413642-1
1
10 C
IC1 2189 2009 Linear IC LA5311M-TP-T1
1
1C
IC2 2105 1533 CMOS IC RH5RA50AA-T1
1
1C
N IC3 2011 9891 LSI TC531001CF-C100
1
1B
IC4 2011 3955 LSI UPD43256BGU-B12
1
1B
X1 2590 1561
Ceramic oscillator
CSTC4.91MGCM-TC
1
5C
R1 2792 0756 Chip resistor MCR10EZHJ563
1
20 C
R2 2795 3213 Chip resistor MCR10EZHG513
1
20 C
R3 2795 3836 Chip resistor MCR10EZHG203
1
20 C
R5 2795 0693 Chip resistor MCR10EZHG123
1
20 C
R6 2795 3269 Chip resistor MCR10EZHG622
1
20 C
R7 2795 2443 Chip resistor MCR10EZHG302
1
20 C
R8 2795 3339 Chip resistor MCR10EZHG152
1
20 C
R9 3122 2009 Chip volume MVR32HXBRN104
1
10 C
R10 2792 0209 Chip resistor MCR10EZHJ104
1
20 C
R11 2792 0845 Chip resistor MCR10EZHJ153
1
20 C
R12,13,15,16 2795 0273 Chip resistor MCR10EZHJ823
4
20 C
R14 2795 0525 Chip resistor MCR10EZHG105
1
20 C
C1,C4~9 2845 1925 Chip capacitor MCH312F105ZP
7
10 C
C2,C3 2845 3486 Chip capacitor MCH312F474ZP
2
10 C
C10~13 2845 1540 Chip capacitor MCH212F104ZK
4
20 C
C14,15 2845 2499 Chip capacitor MCH215A300JK
2
20 C
C18 2845 1547 Chip capacitor MCH215A101JK
1
20 C
86 6408 8020 PCB L370-2 Ass'y A211346A*1
1
1B
N 81 6414 1890 PCB L370-1 Ass'y A110886F*3
1
1B
L370-2 ASS'Y
83 6408 0160 Tape C-L370 A413597-1
1
20 X
85 3501 6538 Miniature jack HSJ1169-012010
1
5X
C16 2805 8700 Electriolytic capasitor ECE-A1AKA2201
1
20 C
IC5 2105 3206 CMOS IC RH5VL40CA-T1
1
10 C
IC6 2101 0952 CMOS IC TC4049BF-TP1
1
1C
Q1 2259 0959 Chip digital transistor DTC114YKT-146
1
20 C
D1 2390 1407 Chip diode MA998-(TX)
1
10 C
D2 2390 0364 Schottky diode MA713-TX
1
10 C
R17 2792 1191 Chip resistor MCR10EZHJ182
1
20 C
R18 2792 0462 Chip resistor MCR10EZHJ473
1
20 C
R19 2792 0470 Chip resistor MCR10EZHJ102
1
20 C
86 6408 8020 PCB L370-2 Ass'y A211346A*1
1
1B
OTHERS
N 6414 1830 EMI Label Z556 A440515-1
1
20 X
N 6411 7670 Label B-L370AHW A415138-2
1
20 X
N 6411 7660 Label B-L370AHQ A415138-1
1
20 X
N 6412 2020 Label D-L370AHQ A414829-2
1
20 X
N 6414 2260 Label C-L370AHQ A440517-1
1
20 X
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 22 —
