– 16 –
IT-G500
5-3-2. Uninstalling the Test Program and Test Data
(1) Remove the microSD card.
(2) Turn ON IT-G500 and execute “
zDiagDelete.exe
” under \\My Device\FlashDisk\DIAG using
Explorer.
(3) When the dialog box appears, tap “Yes”.
(4) The DIAG folder under \\My Device\FlashDisk is deleted, and then IT-G500 restarts.
5-3-3. Start-up of the Test Program
NOTE:
For the special test, see respective items.
Execute
“
Diag_PY024EC.exe
”
under \\My Device\FlashDisk\DIAG using Explorer.
The top menu screen is displayed as shown.
Do not used.
Displays all test items.
Do not select.
Do not used.
PY-024 Test Program Ver x.xx
Top MENU
[1].All Test
[2].Test limited to model (Auto judge)
[3].Pattern Test Log
[4].Assembly Test Log
[5].Test Log Delete
[CLR] -> Exit
5-3-4. Key Operation for Test Program
NOTE:
For the special test, see respective items.
: To select menu screenBS
CLR: To exit from the test program
Numeric Keys: To execute test item

Casio IT-G500 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	CMOS
Scanner type	2D
Tilt reading angle	0 - 25 °
Optical sensor resolution	0.25 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Battery voltage	3.7 V
Power source type	Battery
Battery technology	Lithium
USB version	2.0
Standard interfaces	USB, Bluetooth, Wireless LAN
Connectivity technology	Wireless
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
RAM capacity	512 MB
Keys quantity	22 keys
Product color	Black
LED indicators	Charging, Status
Internal memory	4000 MB
Built-in display	Yes
Housing material	-
Display resolution	480 x 800 pixels
Display technology	LCD/TFT
Processor frequency	1.5 MHz
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67

Weight and Dimensions

Depth	22 mm
Width	74 mm
Height	175 mm
Weight	270 g
