– 17 –
IT-G500
5-3-5. menu screen transition diagram
The following shows the menu transition diagram when “[2] Test limited to model (Auto judge)” is
selected in the top menu.
NOTE:
The menu No. “ MENU-* ” and menu item No. “ [*] ” of each menu screen will vary
depending on the version of the test program.
NOTE:
For the special test, see respective items
NOTE:
After testing, the test result can be visually checked with the color of the test item.
Blue: Test completed successfully.
Red: Test ended incompletely or ended before completion.
( Example )
PY-024 Test Program x.xxxx
xxxxxxxxxxxxxxxx MENU-5
[1].Low Voltage Detection
[2].Current - Run mode
[3].Current - Sleep mode
[4].Current - 2D Scanner
[5].Current - W-LAN
[6].Current - Laser
[9].ECO Charge
[>] -> Next Menu
[<] -> Previous Menu
[CLR] -> Exit
PY-024 Test Program x.xxxx
xxxxxxxxxxxxxxxx MENU-4
[1].Receiver
[2].Headset(Rec&Rep)
[3].Howling Check
[4].Vibrator
[5].2D Scanner Dust Check
[6].Camera
[7].LED Flash
[8].Capacitor Test
[9].NFC Calibration
[0].NFC Magnetic Output
[>] -> Next Menu
[<] -> Previous Menu
[CLR] -> Exit
PY-024 Test Program x.xxxx
xxxxxxxxxxxxxxxx MENU-1
[1].Continuous Test
[2].Key-1
[3].Battery Cover SW (Standard)
[4].TouchPanel
[5].SD Card
[6].External Expansion I/F
[7].Laser Barcode read
[8].2D Scanner Barcode Read
[9].Cradle I/F (USB Host)
[>] -> Next Menu
[<] -> Previous Menu
[CLR] -> Exit
PY-024 Test Program x.xxxx
xxxxxxxxxxxxxxxx MENU-2
[1].micro USB I/F (USB HOST)
[4].NFC Tag ID Read
[6].Headset(Detect & Hook)
[0].Charge(micro USB)
[>] -> Next Menu
[<] -> Previous Menu
[CLR] -> Exit
PY-024 Test Program x.xxxx
Top MENU
[1].All Test
[2].Test limited to model (Auto judge)
[3].Pattern Test Log
[4].Assembly Test Log
[5].Test Log Delete
[CLR] -> Exit
Top MENU
PY-024 Test Program x.xxxx
xxxxxxxxxxxxxxxx MENU-3
[1].LCD
[2].LCD Backlight
[3].LCD Backlight Calibration
[4].Operation LED
[5].Charge(Cradle)
[6].Laser Double Line
[7].Laser Calibration
[8].KEY Backlight
[9].Audio(Rec&Rep)
[0].Speaker
[>] -> Next Menu
[<] -> Previous Menu
[CLR] -> Exit
PY-024 Test Program x.xxxx
xxxxxxxxxxxxxxxx MENU-6
[1].CradleUSB Client
[<] -> Previous Menu
[CLR] -> Exit
