Casio IT-G500 User Manual

– 42 –
IT-G500

Y
WAN (WAN type only)
NOTE:
Insert the SIM card for testing into the SIM card slot before starting test.
<Preparation>
No. Operation Display Test Details
1
Select “Start” – “Settings” –
“Connections” – “WAN
Settings” in that order.
In the WAN Setting screen,
select “Power” tab.
Check “CASIO WAN
Management”, and tap “Apply”
button.
2
Select “Start” – “Settings” –
“Connections” – “Wireless
Manager” in that order.
Check if “Phone” is set to “On”.
If it is not set to “On”, set it to “On”.
<Checking by information display>
No. Operation Display Test Details
1
Select “Start” – “Settings” –
“Connections”– “WAN
Settings” in that order.
Select “Identifi cation” tab.
Check if information on WAN and
SIM card is displayed.

Casio IT-G500 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	CMOS
Scanner type	2D
Tilt reading angle	0 - 25 °
Optical sensor resolution	0.25 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Battery voltage	3.7 V
Power source type	Battery
Battery technology	Lithium
USB version	2.0
Standard interfaces	USB, Bluetooth, Wireless LAN
Connectivity technology	Wireless
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
RAM capacity	512 MB
Keys quantity	22 keys
Product color	Black
LED indicators	Charging, Status
Internal memory	4000 MB
Built-in display	Yes
Housing material	-
Display resolution	480 x 800 pixels
Display technology	LCD/TFT
Processor frequency	1.5 MHz
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67

Weight and Dimensions

Depth	22 mm
Width	74 mm
Height	175 mm
Weight	270 g
