Casio IT-G500

– 70 –
IT-G500
[ Note on reassembling ] SPRING/COIL
Assembling method
Insert the SPRING/COIL into the hole.
In this case, align the spring end with the
slit of the hole.
Turn the SPRING/COIL by 180 degrees.
(2) Remove the LCD MODULE.
LCD MODULE HOLDER/LCD
SPACER/LCD CONNECTOR
TAPE-G/VONNECTOR-PY22
