Casio IT-G500

– 69 –
IT-G500
LCD MODULE
RECIVER
SPACER/INNER CASE
[ Note on reassembling ] RECIVER
Replace it while paying attention to the terminal springs.
[ Note on reassembling ]
SPACER/INNER CASE
Reference positions for attaching the new parts.
(1) Remove the LCD block.
CASE/INNER SPRING/COIL
[ Note on reassembling ]
Be sure that 4 hooks are securely inserted into the I-CASE.
