10. EXPLODED VIEW
DISASSEMBLY
1. Remove 2 screws
P, then remove
battery cover
E and F.
2. Remove 2 AAA-size batteries and 1
lithium battery.
3. Remove 3 screws
\, then remove
the Lower case
0.
4. Remove 3 screws
S, then remove
the Z807-1 ass'y
8.
PCB - Z807 - 2
2
3
4
5
IC9 (5PIN)
IC9 (4PIN)
GND
Q4Q5
3
0
± 2
+ 1
0
IC6 (1PIN)
