11. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
Z807-1 PCB ASS'Y
LSI 6411 1872 COF3000F1 SUB ASS'Y A312545B*8
1
1A
IC1 2011 4088 LSI(RAM) LC3564QM-85
1
1B
N IC2 2012 1176 LSI(ROM) uPD23C1001EAGW-N09
1
1B
IC4 2105 2471 CMOS IC RH5RC502A-T1
1
1C
IC6 3122 2576 Remote control receiver SBX8025-H
1
1C
IC7 2105 0686 L-MOS TC4S69F-TE85R
1
10 C
IC8 2105 2898 L-MOS TC7W04F-TE12L
1
5C
Q1 2250 0700 Chip transistor 2SA1753-ES5,ES6-TB
1
20 C
Q4 2221 0378 Chip transistor 2SC2812-L5,L6-TB
1
20 C
Q5,6,7 2252 0945 Transistor 2SC4577-UT5,UT6-TB
3
20 C
X1 7110 0642 Crystal oscillator DT-26S
1
10 B
X2 2590 1498 Ceramic oscillator CSA3.45MG
1
1B
D1,3 2390 0364 Schottky diode MA713-TX
2
10 C
D2 2390 0959 Chip diode MA721-TX
1
5C
LED1 2370 0945 LED SIR-563SB3F-P,Q
1
10 C
R11 2796 1505 Chip resistor RC210B51K-J-T
1
20 C
R23,31 2792 0470 Chip resistor MCR10EZHJ102
2
20 C
R4 2796 0476 Chip resistor RC210B47K-J-T
1
20 C
R7~10, 2796 1519 Chip resistor RC210B82K-J-T
7
20 C
13,16,17
R12 2796 0315 Chip resistor RC210B33K-J-T
1
20 C
R19,28 2795 2898 Chip resistor MCR10EZHJ106
2
20 C
R20 2796 1239 Chip resistor RC210B2.7K-J-T
1
20 C
R21,27 2796 1246 Chip resistor RC210B240K-J-T
2
20 C
R22,30 2792 0217 Chip resistor MCR10EZHJ101
2
20 C
R24 2795 4179 Chip resistor MCR18EZHJ2R2
1
20 C
R25 2792 0807 Chip resistor MCR10EZHJ470
1
20 C
R26 2792 0831 Chip resistor MCR10EZHJ103
1
20 C
N R32 2795 2233 Chip resistor MCR10EZHJ621
1
20 C
C1 2803 7688 Electrolytic capacitor RC3-6V220M-T10
1
20 C
C3,9,13, 2845 1925 Chip capacitor MCH312F105ZP
6
10 C
14,16,17
C4~8, 2845 1540 Chip capacitor MCH212F104ZK
8
20 C
10,19,25
C11,12 2845 3486 Chip capacitor MCH312F474ZP
2
10 C
N C15 2803 8052 Electrolytic capacitor RC3-T106V100M-T10
1
10 C
C18,26,27 2803 7597 Electrolytic capacitor (v) RC2-16V470M-T10
3
20 C
C20 2845 1652 Chip capacitor MCH215A180JK
1
20 C
C21 2845 1659 Chip capacitor MCH215A150JK
1
20 C
C22,23 2845 2499 Chip capacitor MCH215A300JK
2
20 C
C24 2845 2030 Chip capacitor MCH215C102KK
1
20 C
N C30 2896 1925 Chip capacitor MCH215C391KK
1
20 C
N C32 2803 8059 Electrolytic capacitor RC3-10V330M-T10
1
20 C
N L1 3841 1610 Coil SLF7032T-221MR29-1
1
5C
1 3335 5481 LCD CD428-TS
1
1A
N 2 5610 8830 Heat seal L-Z807 A441084-1
1
5A
3 6408 6940 Adhesive tape A-L172 A412891-4
2
20 C
N 4 6415 3550 Tape A-Z807 A441066-1
1
20 B
5 6408 6950 Adhesive tape B-L172 A412891-5
1
20 C
6 6403 9331 Tape C-L170 A413108-1
1
20 C
7 6408 6960 Tape D-L172 A414156-1
1
20 X
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 25 —
