Casio KL-7000 Service Manual And Parts List

BK : BLAC
K
PARTS LIST GY :
GREY
FOB Japan
N Item Code No. Parts Name Specification Q'ty M N.R.Yen R
BK GY Unit Price
PCB-1 ASS'Y
N 33 6410 7080 Adhesive tape C-L263 C413532-1
1
120 X
N 34 6410 7080 Adhesive tape C-L263 C413532-1
1
120 X
N 50 6410 7011 PC joiner L263 C413507A-1
1
110 X
N 51 4311 9470 PCB-L271-2 A340121-1
1
15 X
C1,C3,C4,C8 2845 1540 Chip capacitor MCH212F104ZK
1
120 C
C9,C11,C13
C14,C15,C17
C37,C22
C10 2803 6155 Chip electrolytic capacitor 16RV2-10-T
1
120 C
N C16 2845 2506 Chip capacitor MCH215F103ZK
1
120 C
C18 2803 6512 Electrolytic capacitor 16RE3-2200-T4-T
1
15 C
C19 2845 1925 Chip capacitor MCH312F105ZP
1
110 C
C2,C7,C38 2845 2289 Chip capacitor MCH215C471KK
1
120 C
C20 2807 6553 Chip electrolytic capacitor 6.3RV2-47-T
1
120 C
C21 2828 5552 Chip electrolytic capacitor 6.3RV2-100-T
1
120 C
C23,C24 2845 2030 Chip capacitor MCH215C102KK
1
120 C
N C25~C35 2845 4501 Chip capacitor MCH215SL101KK
1
120 C
N C301 2803 6624 Electrolytic capacitor (PCB-2) 16RC2-10-T14-T
2
220 C
C302 2845 1540 Chip capacitor (PCB-2) MCH212F104ZK
1
120 C
CN3 3501 6307 Connector S5B-PH-K-S
1
120 C
N CN301 3501 7770 FPC connector (PCB-2) 10FE-ST
1
110 C
N D1 2390 2226 Chip schottky diode RB420D-T146
1
120 C
N D2 2390 1827 Diode MA737- (TX)
1
110 C
D3,D4 2301 2359 Chip diode MA151K- (TX)
1
120 C
EMI2 3013 0602 Inductor SBT-0180W
1
15 C
N EMI3 3035 0308 Ferrite beeds BL01RN1-A63T6
1
120 C
FU1 2114 3227 IC protector ICP-N25-T104
1
110 B
IC1 2105 2667 CMOS IC RH5VL45AA-T1
1
11 B
IC2 2114 2436 Monolithic IC BA12003
1
15 B
N IC3,IC4 2114 3185 Comparator BA10339F-E1
1
110 B
N IC5 2105 3920 CMOS IC S-81252PG-PL-T1
1
110 B
J2 3501 5103 AC adaptor jack HEC3110-01-010
1
110 C
N LSI1 2011 9527 LSI T6C37
1
11 A
N LSI2 2011 9520 LSI CXK5864CM-10LL
1
11 A
N LSI3 2011 9513 LSI TC541000AF-15
1
11 A
N Q2,Q5 2259 0889 Digital transistor DTC144EKT-96
1
120 B
N Q3 2254 0364 FET 2SJ377 (TE16L)
1
11 B
N Q4,Q6 2251 0742 Chip transistor 2SB1051K-S-T146
1
120 B
R1,R2,R6,R34 2792 0462 Chip resistor MCR10EZHJ473
1
120 C
R10,R11 2792 0217 Chip resistor MCR10EZHJ101
1
120 C
R12,R26 2792 0942 Chip resistor MCR10EZHJ332
1
120 C
R13 2795 1792 Chip resistor MCR10EZHJ754
1
120 C
R14 2259 0994 Chip resistor MCR10EZHJ104
1
120 C
R15 2792 0675 Chip resistor MCR10EZHJ331
1
120 C
R16 1907 6212 Chip resistor MCR10EZHJ000
1
110 C
R17 2730 0559 Chip resistor MCR10EZHF3002
1
120 C
R18 2795 1190 Chip resistor MCR10EZHF1002
1
120 C
R19 2795 1701 Chip resistor MCR10EZHF1202
1
120 C
N R20,R21 2795 5334 Chip resistor MCR10EZHF9760
1
120 C
N R22,R23 2795 5341 Chip resistor MCR10EZHF8660
1
120 C
N R24 2795 5348 Chip resistor MCR10EZHF7320
1
120 C
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 20 —
