Casio KL-7000 Service Manual And Parts List

FOB Japan
N Item Code No. Parts Name Specification Q'ty M N.R.Yen R
BK GY Unit Price
N R25 2795 5355 Chip resistor MCR10EZHF4870
1
120 C
R27~R33 2792 0831 Chip resistor MCR10EZHJ103
1
120 C
R3 2792 0815 Chip resistor MCR10EZHJ221
1
120 C
R39 2795 1358 Chip resistor MCR10EZHJ511
1
110 C
R4,R5 2792 0888 Chip resistor MCR10EZHJ334
1
120 C
N R7 2792 0532 Chip resistor MCR10EZHJ105
1
120 C
R8 2730 0547 Chip resistor MCR10EZHJ124
1
120 C
N R9 2792 1051 Chip resistor MCR10EZHJ222
1
120 C
RA1,RA2 2775 1372 Chip network resistor MNR34J5AJ563
1
120 C
VR1 2795 4620 Chip volume MVR32HXBRN502
1
120 C
N X1 2590 1435 Ceramic oscillator EFOEC4004A4
1
110 C
L263E-E4 ASS'Y
N 2 5610 8090 Heat seal L263 C312236-1
1
11 B
N 3 6410 7100 Tape A-L263 C413534-1
1
120 B
N 4 3335 5502 LCD CD427-TS
1
11 B
N 5 6410 7090 Cushion A-L263 C413533-1
2
220 X
N 6 6410 6890 LC holder L263 C312237-1
1
110 X
N 21 6410 7070 Adhesive tape B-L263 C413531-1
1
120 X
N 22 6413 0050 PC joiner B-L263AEJ C440133-1
1
110 X
N 23 6413 0040 PC joiner A-L263AEJ C440132-1
1
110 X
C201,C203 2845 1540 Chip capacitor MCH212F104ZK
1
120 C
C207~C210
C202 2845 2212 Chip capacitor MCH215A100DK
1
120 C
C206 2845 1925 Chip capacitor MCH312F105ZP
1
110 C
LSI201 2001 7287 LSI HD44105H
1
11 B
LSI202 2001 7295 LSI HD44102CH
1
11 B
R201 2795 0826 Chip resistor MCR10EZHG683
1
120 C
R205,R206 2796 0581 Chip resistor MCR10EZHG472
1
120 C
R208,R209
R210~R215 2792 0807 Chip resistor MCR10EZHJ470
1
120 C
VR201 2765 0798 Volume RK09G-J11T-203B
1
11 C
COMPONENT
N 1 6413 4810 Rubber button L271 C111292-3
1
01 X
N 1 6413 6520 Rubber button L271BE C111292-4
0
11 X
N 7 6413 4850 Screw A-L271 A313841-5
14
14 20 X
N 8 6402 6340 Screw A-V465AE A310044-19
3
320 X
N 9 6407 9270 Battery fixing plate L277 A414032-1
1
120 X
10 6396 8870 Battery spring B-L531AA C310675-1
1
120 X
11 6512 5860 Insulation plate L571AM C411701-2
1
120 X
N 12 6410 6980 Battery spring A-L263 C413502-1
1
120 X
N 13 6413 4720 Battery cover L271 C211542-3
1
05 C
N 13 6410 7320 Battery cover L282 C211542-2
0
15 C
N 14 6408 9950 Rubber foot L277 A414533-1
4
420 X
N 15 5041 2318 Screw 2.3 X 6 B
8
820 X
16 6328 1560 Battery spring G49 A44683-1
4
410 X
17 6324 9297 Battery spring C-G164 A43733-1
3
310 X
N 18 6413 4740 Display plate A-L271 A340124-1
1
01 X
N 18 6413 6450 Display plate A-L271BE A340124-2
0
11 X
N 19 6410 7060 Adhesive tape A-L263 C413530-1
1
110 X
N 20 6413 4650 L263E-E4 ass'y C140032*3A
1
11 C
N 24 6413 4820 OP button L271 C312241-3
1
020 C
N 24 6410 7360 OP button L282 C312241-2
0
120 C
N 25 6410 7140 Hang L263 C413553-1
1
120 C
N 26 6410 7110 Spring O P-L263 C413535-1
1
120 C
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 21 —
