Casio KL-7000 Service Manual And Parts List

FOB Japan
N Item Code No. Parts Name Specification Q'ty M N.R.Yen R
BK GY Unit Price
N 27 6413 4660 PCB-1 ass'y A140058*1A
1
11 B
N 28 6410 6990 Battery spring B-L263 C413503-1
1
120 X
29 6329 7620 Battery spring A-G272 A33938-1
1
110 X
30 6393 1710 Nut B-V346 A411430-2
1
120 X
N 31 6413 0010 Adhesive tape D-L263AEJ C440140-1
1
120 X
32 5860 0903 Screw 2.3 X 6 ZMC
11
11 20 X
N 35 6413 4860 Lower cabinet L271 C111285-5
1
01 X
N 35 6413 6560 Lower cabinet L271BE C111285-6
0
11 X
N 36 6413 4770 Label B-L271 A414747-8
1
020 X
N 36 6413 6480 Label B-L271BE A414747-9
0
120 X
N 37 6413 4730 Battery cover B-L271 A313775-8
1
010 X
N 37 6410 7220 Battery cover B-L282 A313775-4
0
110 X
38 6400 9580 Screw L240 A412411-1
1
120 X
N 39 6413 4750 Display plate B-L271 C413501-3
1
010 X
N 39 6410 7390 Display plate B-L282 C413501-2
0
110 X
N 40 6413 4710 Cassette cover L271 C211528-3
1
01 X
N 40 6413 6420 Cassette cover L271BE C211528-4
0
11 X
N 41 6413 4780 Label C-L271 A414471-3
1
120 X
42 6388 8240 Adhesive tape A-V164 A410562-1
1
120 X
N 43 3122 2520 Buzzer KBS-15DA-5C-22
1
110 X
N 44 6413 4760 Label A-L271 A414746-5
1
020 X
N 44 6413 6470 Label A-L271BE A414746-6
0
120 X
N 45 6413 4790 Upper cabinet L271 C111298-2
1
01 X
N 45 6413 6490 Upper cabinet L271BE C111298-3
0
11 X
N 46 6413 4840 Cassette button L271 C312244-3
1
010 X
N 46 6413 6550 Cassette button L271BE C312244-4
0
110 X
N 47 6413 4830 OP hook L271 C312243-3
1
010 X
N 47 6410 7370 OP hook L282 C312243-2
0
110 X
N 48 6413 4800 Cassette case L271 C111286-3
1
05 X
N 48 6410 7260 Cassette case L282 C111286-2
0
15 X
49 6512 5890 Rubber key L571AM C311028-2
1
120 X
N 52 6413 4670 Chassis ass'y C140015*5A
1
01 C
N 52 6413 6510 Chassis ass'y C140015C*6A
0
11 C
53 6402 9720 FCC label L387 A412826-1
0
120 X
N 54 6414 5140 Seal L271 A440616-1
0
120 X
CHASSIS ASS'Y
N 101 6410 6870 Head arm L263 C211543-1
1
15 X
N 102 6413 0060 Chassis sub ass'y C240092*1
1
11 X
N 107 6410 6960 Scissors sub ass'y C312250*1
1
11 B
N 108 6410 7000 Cut plate L263 C413506-1
1
110 X
N 109 6410 7120 Spring T-L263 C413536-1
1
120 X
N 110 6410 7130 Spring S-L263 C413537-1
1
120 X
N 111 6410 2770 Gear B-L278 A313765-1
1
120 X
113 6400 9640 Clutch plate L240 A311853-1
1
120 X
114 6400 9650 Winding gear top L240 A311854-1
1
120 X
115 6400 9710 Clutch felt L240 A412350-1
1
120 X
116 6400 9720 Spring washer L240 A412351-1
1
120 X
117 6400 9730 Clutch spring L240 A412352-1
1
120 X
119 6400 9750 Cut washer B-L240 A412353-2
3
320 X
120 6400 9760 Cut washer C-L240 A412353-3
1
120 X
N 121 6405 2850 Adhesive tape L244 A413501-1
1
120 X
N 122 1013 8689 Thermal head KSH64FK-CA
1
11 X
123 3222 0049 Stepping motor 27S1N18ECNU
1
11 X
N 124 1909 1944 Screw (+) M3 X 5 ZMC-3
2
220 X
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 22 —
