Casio LK-100 Service Manual

N Item Parts code Parts name Specification Q
P
r
i
ce
Code R Remarks
Main PCB
N 1 10243441
PCB ASSY/MAIN TK-RJM506876*001 1
BY A
N
IC3 10240586 IC XC6109N40ANR
1AEC
X1 10070555 CERAMIC OSCILLATOR CSTCW20M0X51-R0
1ACC
N
Q1-4
10207076 TRANSISTOR
KTC601U-GR-RTK/P 4 AA X
Q5-8
10209018 TRANSISTOR
KTA501U-GR-RTK/P 4 AA X
Console PCB
N 2 10243440
PCB ASSY/CNA TK-RJM506875*001 1
CD C
D301 10104646 LED 1154HD-B5/10-90
1
AA C
D310 10201501 IC PC900V0NSZXF
1
AG C
IC302 10189501 IC LA4227-E
1
AF C
D303,306,307,309,
312-319
10079928 DIODE 1SS133TA 12 AA C
IC303,304 10206677 IC NJM2068D-D
1
AH C
N
J303 10209462 JACK DJ-0702O*015
1
AA C
J304 10206815 CONNECTOR JY-6314*01-030
1
AA X
J301 10206816 CONNECTOR JY-6314*01-130
1
AA X
J302 10213695 JACK JY-6316*01-070
1
AC X
N
L303 10231919 COIL RB53-856396NP
1
AA X
N
L304 10231920 COIL RB53-856397NP
1
AA X
Q305 10206676 TRANSISTOR KTC2026-Y-U/P
1
AB X
VR301 69304870 VOLUME EVND8AA03B53
1
AA X
D305 10080347 DIODE 1A2TA
1
AA X
D302 10079931 DIODE DZ5.1BSCTA
1
AA X
D308,311 10085189 ZENER DZ5.6BSBTA
2
AA X
D304 10079929 DIODE SRT14TA
1
AA X
N
L301,302,305 10222984 COIL CNSS-823465NP
3
AA X
N
Q301 10206675 TRANSISTOR KTA1273-Y-AT/P
1
AA X
Q302,304 10206673 TRANSISTOR KTC3199-GR-AT/P
2
AA X
Q303 10209015 TRANSISTOR KTD863-GR-AT/P
1
AA X
LED PCBs
3 10133541 PCB ASSY/LDA TK-RJM503432*001
1
BL C
4 10059364 PCB ASSY/LD3M TK-M240428*1(M478)
1
BA C
5 10036271 PCB ASSY/LD4M TK-M240429*1(M475)
1
AT C
6 10036272 PCB ASSY/LD5M TK-M240430*1(M475)
1
AT C
LED501-536
23701408
LED SLI-332URCTJ2 36
AA X
Keyboard unit
N 7 10243430
PCB ASSY/KYA TK-RJM503929*004 1
AR C
D701-D761
10079928
DIODE 1SS133TA
61 AA X
8
10014608 KEY SET/WHITE/CB M340489A*3 4
AU C
9
10014609 KEY SET/WHITE/CS M340489A*4 1
AV C
10 69251730 KEY SET/BLACK/5P M140369-2
1
AM C
11 69251720 KEY SET/BLACK/10P M140369-1
2
BN C
N12
10243429 RUBBER/CONTACT TK-RJM503856*001 1
AQ C
Notes N-New parts
Q-Quantity used per unit
- 11 -

Casio LK-100 Specifications

General

MIDI-keyboard number of keys	61 keys
Interface	USB
DC-in jack	Yes
Dimensions (WxDxH)	945 x 373 x 135 mm
Power requirements	9 V DC

Weight and Dimensions

Weight	4700 g
