Terminals
SUSTAIN/ASSIGNABLE JACK
: Standard jack (sustain, sostenuto, soft, rhythm start/stop)
HEADPHONE/OUTPUT Jack
: Stereo standard jack
Output Impedance: 100Ω
Output Voltage: 4V (RMS) MAX
Microphone In: Standard jack (with microphone volume knob)
Input impedance: 3KΩ
Input sensitivity: 10mV
USB port
VIDEO OUT Jack: Output Voltage: 1Vp-p MAX
Power Jack: 9V DC
Power Supply: 2-way
Batteries: 6 AA-size batteries
Battery Life: Approximately 2.5 hours continuous operation on alkaline batteries
AC Adaptor: AD-5
Auto Power Off: Turns power off approximately 6 minutes after last key operation. Enabled under batter
power only, can be disabled manually.
Speaker Output: 2.5W + 2.5W
Power Consumption: 9V
7.7W
Dimensions: 94.4 × 38.7 × 14.2 cm (37
3
/16 × 15
1
/4 × 5
9
/16 inch)
Weight: Approximately 5.1kg (11.2 lbs)(without batteries)
• Design and specifications are subject to change without notice.
