— 9 —
3. Remove the battery cover and disengage the battery.
4. Remove 3 screws.
Screw
Screws
Printer cover
Take-up reel
3. DISASSEMBLY
■
Removing the upper case block
1. Remove the Printer cover.
2. Remove two Roll paper and theTake-up reel.
