Casio PCR-T500 User Manual

E-12
To use the cash register’s basic function
 To install journal paper
1 Repeat steps 1 through 5 of “To install receipt paper”.
2 Using f key, feed the paper about 20 cm
3 Remove the paper guide of the take-up reel.
4 Slide the leading end of the paper into the groove on the spindle of the
take-up reel and wind it onto the reel two or three turns.
5 Replace the paper guide of the take-up reel.
6 Place the take-up reel into place behind the printer, above the roll
paper.
7 Press the f key to take up any slack in the paper.
8 Replace the printer cover.
SES800INC-e.indbE-12SES800INC-e.indbE-12 2013/10/0113:04:552013/10/0113:04:55

Casio PCR-T500 Specifications

General

Paper Width	58mm
Display	LCD
Printer	Single Station Thermal Printer
Connectivity	SD Card Slot
PLUs	2000
Printing Speed	14 Lines per Second
Power Source	AC Adapter
Dimensions	400mm x 450mm x 220mm
Cash Drawer	5 coin
