SE-G1/PCR-T273/SM-T274
– 8 –
C-5. Loosen the nut and disconnect the ground wire.
C-6. Disconnect the DRAWER connector.
C-7. Remove the COVER/PCB.
Connector
Ground wire
C-8. Place the DRAWER back in the MAIN UNIT.
C-9. Undo one screw.
C-10.Slide the MAIN UNIT toward the back to remove it.
MAIN UNIT
Screw(S4)
COVER/PCB
