Casio SE-G1 Manual

SE-G1/PCR-T273/SM-T274
– 36 –
PARTS LIST
1 DL-2816
2 DL-2817
12
N 1 10445372 CASE/MAIN RJE502983-002V02 1 B
N 1 10447862 CASE/MAIN RJE502983-003V02 1 B
2 55000619 ROLLER/DELRIN DR-19B1 4 4 B
3 10236805 LEVER/HOOK E341286-001V03 1 1 C
4 10127603 AXIS/LEVER HOOK RJE500674-001V01 1 1 C
5 10201068 LOCK/SPRING RJE500007-001V02 1 1 C
6 62465010 SPRING/PRESS E412069-1 1 1 X
7 10078759
RAIL/MLED18
E240841-1 1 1 C
8 10078760
RAIL/MRED18
E240842-1 1 1 C
9 10194208 RUBBER/DUMPER RJE500005-001V02 4 4 X
10 10167366 RUBBER/PAD RJE501204-001V01 4 4 C
11 10080191 SOLENOIDO SUB ASSY E341301*4 1 1 B
12 10203849 DRAWER SUB ASSY E341274*001V03 1 1 C
13 52000106 RIVET 5X30 1 1 X
N 14 10447858 LOCK/CYLINDER RJE502350*002V01 1 1 C
N 15 10324878 PANEL/FRONT RJE502991-001V01 1 C
N 15 10447857 PANEL/FRONT RJE502991-002V01 1 C
16 10445633 BILL COIN CASE ASSY RJE501368*10 1 1 C
17 10230104 BILL HOLDER SUB ASSY E341290*002V04 4 4 C
18 10276626 SPRING/BILL HOLDER E441357-001V03 4 4 A
19 10194233 PLATE/BILL HOLDER E240845-001V02 1 1 X
N 20 10445634 CASE/BILL RJE504023-001V01 1 1 X
21 10298559 CASE/COIN RJE500217-002V02 1 1 C
22 10298554 SEPARATER/COIN RJE500216-002V02 6 6 B
N 23 10298555 SEPARATER/BILL RJE500219-002V02 3 3 B
N1 6-NUT N-HXT1-6Z3 2 2
N2 6-NUT N-HXT1-4Z3 1 1
W1 WASHER W-6X13-1.0Z3 2 2
W2 WASHER 6X13X1.0 ZMC-3 2 2
S1 SCREW S-WSPT-4X10Z3 6 6
S2 SCREW S-PADLMA-4X25Z3 1 1
S3 SCREW 3X10 NI 4 4
S4 SCREW 3X8 ZMC-3,, 3 3
S5 SCREW 3X5 NI... 4 4
S6 SCREW
R
Q'TY
N Item Code No. Parts Name Specification

Casio SE-G1 Specifications

General

Clerk lock	Yes
Memory type	Flash ROM
Number of users	8 user(s)
Keyboard number of keys	34
Supported paper width	58 mm
Backlight	No
Display digits	8 digits
Display number of lines	1 lines
Second display number of characters	8
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power source	AC
Power consumption	100 mA

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3500 g
