— 14 —
2. Remove the three screws and two connectors (CN2, CN3).
Remove the PCB ass’y (E466-ARC: Option).
■ PRINTER
1. Remove the six screws.
Remove the printer block.
■ POWER SUPPLY
1.1 Remove the five screws.
2 Remove the four screws.
Remove the power supply.
To Next Page
