6-2. REMOTE DISPLAY
6-3. HANDY SCANNER
6-4. REMOTE PRINTER / SLIP PRINTER
Connect the following peripherals to the COM ports respectively.
HANDY SCANNER : COM2
REMOTE PRINTER/ : COM1, 2, 3
SLIP PRINTER
2
2
2
2
11
6-5. DRAWER
6-5-1. CONNECTOR THE DRAWER
1. Connector drawer connector (three color lead on drawer)
to the cash register.
2. Connector frame drawer connector (green lead on drawer)
to the cash register.
6-5-2. CONNECTOR THE DRAWER
1. Screw in 2 fixing screws bottom side of the register.
2. Stick rubber plate on the eash corner of the bottm side of
the register.
3. Mount the cash register on the top of the drawer, ensuring
that the feet on the bottom of the cash register go into the
holes on the drawer
PC/MODEM SCANNER
COM1 COM2 COM3
COM4 COM5
INLINE1
COM4 COM1 COM2 COM3
Power cord
Rear side of the terminal
To Next Page
