Casio TE-8000F Service Manual

N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
N 94 94870776 SCREW 1073844 2 2 2 2 2 2 2 AB X
N 95 94870777 CUTTER/FIXED 1231681 1 1 1 1 1 1 1 BK A
N 96 94870778 SPRING 1231999 1 1 1 1 1 1 1 AA B
N 97 10114233 CHASSIS/PR L RJE500466-1 1 1 1 1 1 1 1 AR C
N 98 10114234 CHASSIS/PR R RJE500470-1 1 1 1 1 1 1 1 AR C
N 99 10114235 CHASSIS/PR C RJE500474-1 1 1 1 1 1 1 1 AR C
N 100 10114236 CHASSIS/PR MOUNT RJE500446-1 2 2 2 2 2 2 2 AC C
N 101 10114237 SHAFT/E468 RJE500450-1 2 2 2 2 2 2 2 AC C
SCREW S-PASLMA-3X5ZC 4 4 4 4 4 4 4 X
SCREW S-PAMA-3X5ZC 6 6 6 6 6 6 6 X
N 102 10114238 E-RING R-ER-3TCBL 4 4 4 4 4 4 4 AA C
N 103 10113437 COVER/PR PROTECT RJE500467-1 1 1 1 1 1 1 1 AF C
N 104 10104346 COVER/CUTTER RJE500329-1 1 1 1 1 1 1 1 AR C
9. Clerk switch circuit
N 105 10104389 PCB ASSY/E468-E6 RJE500416*1 1 1 1 1 1 1 1 CN B
IC1,2,5 10005662 IC/CMOS SN74LV374APWR 3 3 3 3 3 3 3 AF A
IC3,4,6 21120823 IC BA12003BF-E2 3 3 3 3 3 3 3 AF A
R1,2,7 RESISTOR/CHIP MCR03EZHJ000 3 3 3 3 3 3 3 X
R11-13,15-21, RESISTOR/CHIP MCR03EZHJ101 17 17 17 17 17 17 17 X
24-30
R3,5,8,10,22 RESISTOR/CHIP MCR03EZHJ103 5 5 5 5 5 5 5 X
R4,6,9,14,23 RESISTOR/CHIP MCR03EZHJ471 5 5 5 5 5 5 5 X
RM1-5 27753288 RESISTOR/CHIP NETWORK MNR14E0ABJ103 5 5 5 5 5 5 5 AA C
C2,4,6 CAPACITOR/CHIP GRM1882C1H101JA01D 3 3 3 3 3 3 3 X
C1,3,5 CAPACITOR/CHIP GRM188B11E104KA01D 3 3 3 3 3 3 3 X
C7 28073647 CAPACITOR/ELECTROLYTIC RV2-16V101MS-R 1 1 1 1 1 1 1 AA C
D1-15 10009218 DIODE/CHIP 1SS400TE61 15 15 15 15 15 15 15 AA B
Q1-5 22501603 TRANSISTOR/CHIP 2SB1182TLQR 5 5 5 5 5 5 5 AC B
CN2 35405184 CONNECTOR HFW10S-2STE1 1 1 1 1 1 1 1 AB C
CN1 35405185 CONNECTOR HFW12S-2STE1 1 1 1 1 1 1 1 AB C
N CN6 10105680 CONNECTOR HFW4R-2STE1 1 1 1 1 1 1 1 AF C
CN5 35405190 CONNECTOR SFW27R-5STE1 1 1 1 1 1 1 1 AE C
SW1-10 34121029 SWITCH/TACT SKHHAL 10 10 10 10 10 10 10 AA B
CN3 35017728 CONNECTOR B14B-PHDSS 1 1 1 1 1 1 1 AB C
CN4 35802364 CONNECTOR B30B-PHDSS 1 1 1 1 1 1 1 AE C
10. Connector board
N 106 10105423 PCB/E468-CNB1 RJE500415-1 1 1 1 1 1 1 1 AD C
N CN1 10105422 CONNECTOR HLW25R-2C7 1 1 1 1 1 1 1 AE C
CN2-4 30007917 CONNECTOR ID9P33E4GX28 3 3 3 3 3 3 3 AK C
11. ARCNET In-line board
N 107 10105420 PCB/E468-ARC RJE500412-1 1 1 1 1 1 1 1 AF C
N IC1 10105419 IC HYC2000 1 1 1 1 1 1 1 BV A
R5 10074510 REGISTOR/CHIP RD25SM10-6101J 1 1 1 1 1 1 1 AA X
N R3,4 10082973 REGISTOR/CHIP RD25SM10-6154J 1 1 1 1 1 1 1 AA X
N C1 10073686 CAPACITOR ECQ-V1H104JZW 1 1 1 1 1 1 1 AD X
C2 10073688 CAPACITOR/ELECTROLYTIC RE3-16V470M 1 1 1 1 1 1 1 AA C
C3,4 10074512 CAPACITOR DEA1X3A180JC1B 2 2 2 2 2 2 2 AA X
N CN2,3 35020073 CONNECTOR TM5RJ3-88 2 2 2 2 2 2 2 AT C
N SW1 10105421 SLIDE SWITCH SSSU111400 1 1 1 1 1 1 1 AI C
CN1 35016307 CONNECTOR S5B-PH-K-S 1 1 1 1 1 1 1 AA C
12. Other
N 108 10103367 BATTERY/LITHIUM VL3032/SGB 1 1 1 1 1 1 1 CQ A
10029671 SCREW/DRAWER E441149-1 2 2 2 2 2 2 2 AF C
