• CPU Name HD6417706AF133
Number of control bit 32 bit
Internal RAM 16 KBytes
• DRAM Name MD56V62160E-10TAB0
Capacity 64 Mbits (8 MBytes)
• Flash ROM Name MBM24DL324BE90PFTN
Capacity 4 MBytes
• I/O controller Name uPD784215AGC-XXX-8EU
• Gate array Name uPD65945GJ-P16-JEU
• LCD controller Name S1D13705F00A100
• ARCNET controller Name COM20019ILJP
• Switching power supply Name SPS-468
• LCD unit Name KCG057QV1DB-G00
• Inverter unit Name PS2-70052-001
• Themal printer Name M-T203A-001(receipt)
M-T203-001(journal)
Print method Impression heat line dot
Head specification Total dot number : 432 dots/dot line
Dot pitch : Length 8 dots/mm
Wide 8 dots/mm
Paper cut Auto-paper cut
Paper supply method Drop-in paper loading
• Roll paper Type Heat-sensitive paper
Size 57.5±0.5mm
Roll diam φ 83 or less
Thickness 75±3µm
1. SPECIFICATIONS
1-1. Electrical specifications
1-2. Environmental specifications
1-3. Main components
• Operating temperature 0 °C ~ 40 °C
• Operating humidity 10 % ~ 85 %
• Storage temperature -20 °C ~ 65 °C
• Storage humidity 10 % ~ 85 %
• Vibration strength 1.5 G (The machine must be in the carton box)
120 V 220 V 230 V 240 V
•Power consumption In operation Max. 0.9 A 0.6 A 0.6 A 0.6 A
stand-by Max. 0.15 A 0.15 A 0.15 A 0.15 A
•Memory protection Back-up battery VL3032/SGB (Vanadium lithium battery)
Back-up period 30 days (25 °C)
Battery life Replace the battery every 5 years.
Recharge time 48 hours (full charge)
•Clock & Calendar Accuracy Within ± 30 sec. per month (25 °C)
Auto calendar Effective until 2099 A.D.
