Casio TE-8000F Service Manual

N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
SCREW S-PASEMA-4X5ZC 1 1 1 1 1 1 1 X
SCREW S-PASEMA-3X6ZC 2 2 2 2 2 2 2 X
N 10115091 FG CABLE SUB ASSY RJE500484*1 1 1 1 1 1 1 1 AB C
N 16 10113436 HOLDER/HINGE E468 RJE500441-1 1 1 1 1 1 1 1 AD C
N 10114087 SHEET/BLIND E468 RJE500443-1 1 1 1 1 1 1 1 C
3. Customer Display block
N 17 10104422 CASE/RDP E468 RJE500324-1 1 1 1 1 1 1 1 AS C
N 18 10104421 PANEL/RDP E468 RJE500323-1 1 1 1 1 1 1 1 AT B
19 43081401 PCB/E445A-E2-2 E340800-1 1 1 1 1 1 1 1 AF X
LED3-7 23201365 LED/7SEG HDSP-5621#S02 5 5 5 5 5 5 5 AP B
LED1,2 24088398 LED GL8EG42 2 2 2 2 2 2 2 AA B
CN2 35405193 CONNECTOR HLW10R-2C7 1 1 1 1 1 1 1 AB C
CN1 35405194 CONNECTOR HLW12R-2C7 1 1 1 1 1 1 1 AB C
N 20 10104445 CABLE/C E468 E440657-12 1 1 1 1 1 1 1 AF C
N 21 10114075 CABLE/D E468 E440657-13 1 1 1 1 1 1 1 AG C
N 10115537 CUSION/A E468 RJE500539-1 1 1 1 1 1 1 1 AA X
4. Button block
N 22 10104418 FRAME/KB E568 E140258-3 1 1 1 1 1 1 1 AG C
23 62467810 KETTOP/S E311101A-4 41 41 41 41 41 41 41 AA B
24 62467768 KETTOP/L E210963A-4 2 2 2 2 2 2 2 AD B
25 62210371 CAP/S E311103A-1 29 29 29 29 29 29 29 AA B
26 62213988 CAP/L E210964-1 2 2 2 2 2 2 2 AB B
27 62457250 BUTTON/1 E311792-1 1 1 1 1 1 1 1 AB C
28 62457260 BUTTON/2 E311792-2 1 1 1 1 1 1 1 AB C
29 62457270 BUTTON/3 E311792-3 1 1 1 1 1 1 1 AB C
30 62457280 BUTTON/4 E311792-4 1 1 1 1 1 1 1 AB C
31 62457290 BUTTON/6 E311792-5 1 1 1 1 1 1 1 AB C
32 62457300 BUTTON/7 E311792-6 1 1 1 1 1 1 1 AB C
33 62457310 BUTTON/8 E311792-7 1 1 1 1 1 1 1 AB C
34 62457320 BUTTON/9 E311792-8 1 1 1 1 1 1 1 AB C
35 62457330 BUTTON/0 E311792-9 1 1 1 1 1 1 1 AB C
36 62457340 BUTTON/. E311792-10 1 1 1 1 1 1 1 AB C
37 62457350 BUTTON/00 E311792-11 1 1 1 1 1 1 1 AB C
38 62457360 BUTTON/5 E311116-4 1 1 1 1 1 1 1 AB C
39 62480990 RUBBER/CONTACT E411877A-1 43 43 43 43 43 43 43 AA B
40 62473830 SPRING/COIL E411104A-1 2 2 2 2 2 2 2 AA B
SCREW S-WBPT-3X8ZC 20 20 20 20 20 20 20 X
41 62473837 SPRING/COIL E411104A-2 2 2 2 2 2 2 2 AA B
42 62481751 FPC/E545 E240508A-1 1 1 1 1 1 1 1 BI B
43 62481313 SHEET/COMMON E240509-1 1 1 1 1 1 1 1 AX B
44 62481314 SPACER/E545 E240510-1 1 1 1 1 1 1 1 AG C
45 62481315 CHASSIS/KB E545A E340740-1 1 1 1 1 1 1 1 AF C
46 62481316 CHASSIS/KB E545B E340741-1 1 1 1 1 1 1 1 AH C
47 62481749 RUBBER/CONTACT E240505A-1 1 1 1 1 1 1 1 BM B
%- PLATE/S E240526-6 1 1 1 1 1 1 1 X
- PLATE/S E240526-7 1 1 1 1 1 1 1 X
RECEIPT FEED PLATE/S E240526-61 1 1 1 1 1 1 1 X
JOURNAL FEED PLATE/S E240526-62 1 1 1 1 1 1 1 X
RECEIPT PLATE/S E240526-63 1 1 1 1 1 1 1 X
#/NS PLATE/S E240526-66 1 1 1 1 1 1 1 X
RF PLATE/S E240526-67 1 1 1 1 1 1 1 X
C PLATE/S E240526-69 1 1 1 1 1 1 1 X
OPEN PLATE/S E240526-71 1 1 1 1 1 1 1 X
RC PLATE/S E240526-73 1 1 1 1 1 1 1 X
CHK/TEND PLATE/S E240526-78 1 1 1 1 1 1 1 X
PD PLATE/S E240526-83 1 1 1 1 1 1 1 X
NEW/OLD CHK PLATE/S E240526-88 1 1 1 1 1 1 1 X
CR PLATE/S E240526-91 1 1 1 1 1 1 1 X
NB PLATE/S E240526-92 1 1 1 1 1 1 1 X
CANCEL PLATE/S E240526-108 1 1 1 1 1 1 1 X
X PLATE/S E240526-109 1 1 1 1 1 1 1 X
VOID PLATE/S E240526-110 1 1 1 1 1 1 1 X
YES PLATE/S E240526-111 1 1 1 1 1 1 1 X
- 122 -
