Casio TK-950 Service Manual

— 61 —
1 TE-900
2 TE-1500
3 TK-950
4 TK-1550
1 2 3 4
3.CUSTOMER DISPLAY BLOCK
4 10272394 CASE/REAR DISPLAY RJE502341-001V01 1 1 1 1 C
5 10272398 PANEL/REAR DISPLAY RJE502347-001V01 1 1 1 1 C
6 10275915 CABLE/FFC JOINER E441341-011V01 1 1 1 1 C
7 10275916 CABLE/FFC JOINER E441341-012V01 1 1 1 1 C
8 10275677 PCB ASSY/E283-E22 RJE502385*001V01 1 1 1 1 A
D1,D2,D3,D4 10072597 LED/7SEG HDSP-521G 4 4 4 4 B
4.BUTTON BLOCK (STROKE)
9 10291845 FLAME/KEY RJE502288-002V02 1 1 X
10 10300645 BUTTON/1 RJE501915-049V02 1 1 X
11 10300646 BUTTON/2 RJE501915-050V02 1 1 X
12 10300647 BUTTON/3 RJE501915-051V02 1 1 X
13 10300649 BUTTON/4 RJE501915-052V02 1 1 X
14 10300650 BUTTON/5 RJE501915-053V02 1 1 X
15 10300651 BUTTON/6 RJE501915-054V02 1 1 X
16 10300652 BUTTON/7 RJE501915-055V02 1 1 X
17 10300653 BUTTON/8 RJE501915-056V02 1 1 X
18 10300654 BUTTON/9 RJE501915-057V02 1 1 X
19 10300655 BUTTON/0 RJE501915-058V02 1 1 X
20 10300656 BUTTON/. RJE501915-059V02 1 1 X
21 10299891 BUTTON/00 RJE501915-060V02 1 1 X
22 10241195 CAP/S E341251-002V02 51 58 A
23 10241196 CAP/L RJE500370-002V02 3 2 A
24 10274307 CAP/LLL RJE500374-002V02 1 1 A
25 10088889 KEYTOP/S E341250-2 63 70 A
26 10241194 KEYTOP/L RJE500369-002V02 3 2 A
27 10276421 KEYTOP/LLL RJE500372-002V02 1 1 A
28 10166869 RUBBER/CONTACT RJE501209-001V01 67 73 B
29 10072611 SPRING/COMPRESS E441298-1 4 3 C
30 10072612 SPRING/COMPRESS E441298-2 6 6 C
31 10276423 SHEET/COMMON RJE502283-001V01 1 1 B
32 10276424 SPACER RJE502284-001V01 1 1 C
33 10276422 SHEET/FPC RJE502282-001V01 1 1 B
34 10274354 CHASSIS/BUTTON RJE502285-001V01 1 1 C
5.BUTTON BLOCK (COMBINATION)
35 10291843 FLAME/KEY RJE502272-002V02 1 1 X
36 10300645 BUTTON/1 RJE501915-049V02 1 1 X
37 10300646 BUTTON/2 RJE501915-050V02 1 1 X
38 10300647 BUTTON/3 RJE501915-051V02 1 1 X
39 10300649 BUTTON/4 RJE501915-052V02 1 1 X
40 10300650 BUTTON/5 RJE501915-053V02 1 1 X
41 10300651 BUTTON/6 RJE501915-054V02 1 1 X
42 10300652 BUTTON/7 RJE501915-055V02 1 1 X
43 10300653 BUTTON/8 RJE501915-056V02 1 1 X
44 10300654 BUTTON/9 RJE501915-057V02 1 1 X
45 10300655 BUTTON/0 RJE501915-058V02 1 1 X
46 10300656 BUTTON/. RJE501915-059V02 1 1 X
47 10299891 BUTTON/00 RJE501915-060V02 1 1 X
48 10241195 CAP/S E341251-002V02 26 26 A
49 10241196 CAP/L RJE500370-002V02 2 2 A
50 10088889 KEYTOP/S E341250-2 38 38 A
51 10241194 KEYTOP/L RJE500369-002V02 2 2 A
52 10276644 RUBBER/CONTACT RJE502275-001V01 1 1 B
53 10072611 SPRING/COMPRESS E441298-1 2 2 C
N Item Code No. Parts Name Specification
Price
code
R Remarks
Q
