Casio V-R100 Service Manual

V-R100
– 48 –
1 V-R100-BD (DLS Europe)
2 V-R100-A (Australia)
3 V-R100-B (DI Europe)
4 V-R100-K (DI UK)
5 V-R100-C (US/Canada)
6 V-R100-DD (DLS UK)
7 V-R100-T (Taiwan)
1234567
N Item Code No. Parts Name Specification
Q'ty
R
8. R-CASE-ASSY
N 8-1 10410049 CASE/REAR RJE503837-001V02
1111111X
N 8-2 10409533 BLIND/DALLAS RJE503838-001V01 1111 1X
N 8-2 10409514 COVER/DALLAS RJE503839-001V01 1 1 X
N 8-3 10409515 HOLDER/SP RJE503865-001V01
1111111X
N 8-4 10409516 SPEAKER 2828CP08P1-21(GP)
1111111B
N 8-5 10413620 RUBBER/DUMPER RJE503913-001V01
2222222X
S10 SCREW S-BD-PT-3X8Z3
3333333X
S11 SCREW S-BD-PT-2X6Z3
2222222X
9. ACCESSORIES
N 10414056 SPACER/RP RJE503923-001V01
1111111C
N 10408175 COVER/DUST RJE503876-001V01
1111111C
N 10386351 PLATE/MAGNET RJE500927*002V03 1111111C
N 10331637 TRAY SUBASSY RJE503185*001V01 1111111C
N 10416623 CORE/FERRlTE GIFC-20-10-10 1111111X
N 10435487 STOPPER/DISPLAY RJE503959-001V01
1111111X
