Casio V-R100 Service Manual

V-R100
– 50 –
6-4. DRAWER (DL-2436/2814/2815) PARTS LIST
1 DL-2814
2 DL-2815
3 DL-2436
123
1 10203171 RUBBER/FOOT CASE RJE500667-001V02 4 4 4 X
2 10167366 RUBBER/FOOT RJE501204-001V01 4 4 4 X
3 10230100 CABLE/FG RJE500104*001V03 1 1 1 X
4 10408590 METAL/TRAP RJE503885-001V01 1 1 1 X
5 10378459 ROLLER/DELRIN PB-19B1 4 4 4 B
6 52000106 RIVET 5X30 1 1 1 X
7 10203374 LOCK/CYLINDER CL-23 1 1 1 C
8 10292500 PANEL/FRONT RJE501385-002V01 1 1 1 C
9 10407658 SUBASSY/DRAWER RJE503828*001V01 1 1 1 X
10 10194208 RUBBER/DUMPER RJE500005-001V02 4 4 4 X
11 10407600 CHASSIS/BOTTOM RJE503822-001V01 1 1 1 X
12 10413852 LOCK ASSY RJE500567*008V01 1 C
12 10413853 LOCK ASSY RJE500567*009V01 1 1 C
13 10230104 SUBASSY/BILL HOLDER E341290*002V04 4 4 5 A
14 10276626 SPRING/BILL HOLDER E441357-001V03 4 4 5 A
15 10194233 BRACKET/BILL HOLDER E240845-001V02 1 1 1 X
16 10298565 CASE/BILL E140505-002V03 1 1 1 X
17 10298555 SEPARATER/BILL RJE500219-002V02 3 3 4 X
18 10298559 CASE/COIN RJE500217-002V02 1 1 X
18 10298560 CASE/COIN RJE500284-002V02 1 X
19 10298554 SEPARATER/COIN RJE500216-002V02 6 6 X
19 10298556 SEPARATER/COIN RJE500285-002V02 4 X
S1 SCREW S-WBST-4X6Z3 4 4 4 X
S2 SCREW S-WBST-3X8Z3 2 2 2 X
S3 SCREW 3X6 NI 2 2 2 X
S4 SCREW 4X5 ZMC-3 2 2 2 X
S5 SCREW 3X8 ZMC-3,, 3 3 3 X
S6 SCREW 3X5 NI... 4 4 5 X
S7 SCREW S-WBST-3X6Z3 9 9 9 X
N1 NUT 6 ZMC-3 2 2 2 X
W1 WASHER 6X13X1.0 ZMC-3 4 4 4 X
Specification
Qt'y
RN Item Code No. Parts Name
