Casio WK-6600 User Manual

Reference
E-117
• Design and specifications are subject to change without notice.
Inputs/Outputs
USB jack TYPE B
Sustain/Assignable jack Standard jack (sustain, sostenuto, soft, start/stop)
Phones jack Stereo standard jack
Line Out R, L/MONO jacks Standard jack × 2
Output Impedance: 2.3kΩ, Output Voltage: 1.5V (RMS) MAX
Audio In jack Stereo mini jack
Input Impedance: 9kΩ, Input Sensitivity: 200mV
Mic In jack (WK-6600 only) Standard jack (connect a dynamic microphone only)
Input Impedance: 3kΩ, Input Sensitivity: 10mV
Power Jack 12V DC
Power Supply 2-way
Batteries 6 D-size zinc-carbon batteries or alkaline batteries
Battery Life Approximately 4 hours continuous operation on alkaline batteries
AC Adaptor AD-A12150LW
Auto Power Off Approximately 6 minutes after last key operation (during battery use),
approximately 4 hours after last key operation (during AC adaptor use)
Speakers 12cm × 2 + 3cm × 2 (Output: 6.0W + 6.0W)
Power Consumption 12V = 18W
Dimensions CTK-6200: 94.8 × 38.4 × 12.2 cm (37
3
/8 × 15
1
/8 × 4
13
/16 inch)
WK-6600: 116.1 × 38.5 × 14.7 cm (45
3
/4 × 15
3
/16 × 5
13
/16 inch)
Weight CTK-6200: Approximately 5.7kg (12.6 lbs) (without batteries)
WK-6600: Approximately 7.2kg (15.9 lbs) (without batteries)

Casio WK-6600 Specifications

General

Control type	Buttons
MIDI-keyboard number of keys	76 keys
Metronome	Yes
Product color	Black
Sound effects	Chorus, Equalization, Flanger/Digital Signal Processing (DSP), Reverberation
Volume control	Digital
Maximum polyphony (notes)	48
Music memory capacity (songs)	5
Interface	USB
Headphone outputs	1
Display type	LCD
Battery type	D
Power source type	AC, Battery
Number of batteries supported	6
Cables included	AC

Weight and Dimensions

Depth	385 mm
Width	1161 mm
Height	147 mm
Weight	7200 g
