7- Loosen (don't take off)the screws P which will f i x the
parts B a nd C ( pa r t s in fo r m of an L) on hor izontal bar.
8- Keep the "down-stop" (part D) in the direction of the
lenght of the horizontal bar and bring up ( b y hand) the hammer
support and hammer ( the hammer is similar to a long wedge).
Make th em pen etr at e in to th e wedge distributor until the
hammer support comes up higher than the down stop (Part D ) .
Now turn the down stop (part D) into a 90° position to
horizontal bar so that hammer support remains sitting on the
part D.
9- Tighten the screw of the Part D (down-stop) (Allen
wrench no 5, in accessory box), and let the hammer support
sitting on it.
10- Fix the start-of-travel switch (Part C) with the
screws P paying attention that the button of the switch is
upside (like in drawing FIG 1.1).
11- Now, to f ix the part B ( in f or m of an " L" ) you ne e d
to bring up the whole mechanism. For this, pus h up the whole
mechanism fr om th e buttom of the stapling cylinder ( ai r
piston); bring up the mechanism until the part E ( start of
travel stop, in for m of ) comes up higher than the
screws where th e pa rt B will be fixed.
12- Fix the part B to the screws and tighten the screws.
Now the part E should be resting on part B.
The horizontal bracket (Part E on drawing FIG 1) should
be now in upper position.
Put back the side (gre y) casings of the machine and
connect the machine to both an air and power supply.
Follow the Operation instructions of the Manual so to set
up, to adjust an d to make your first joinings tests.
