-1-
INSTRUCTIONS FOR USE :
OPERATIONS (see figure 1)
The Underpinner can work in 2 modes :
• Key MA N : The foot pedal operates the moulding clamp an d
wedges are inserted by pressing the buttons (Z).
• Key AUTO : The pedal operates both the clamping a nd the
insertion of the wedges.
The red panic button can be used as a general clearing key.
For safety reasons, insertion of wedges can only be done when
there are mouldings present in the machine.
Initial wedge insertion can either be at the front or ba ck
depending on which arrow indicator is lit.
Selection of the number of wedges is decided by the keys 1 &
2.
Wedge insertion will start according to the selection of the
or .
key 1 and the position chosen for the arrow key
if lights up, this indicates that the wedge cartridge is
empty. If the wedge insertion cycle has not been completed the
machine will stop but the mouldings will remain clamped. After
changing the cartridge , the cycle is continued by pressing the
button ''agrafage'' (Z)
If the ''incident' ' indicator lights up, it shows there is a
problem in the machine and it will stop.
