dealer immediately if any parts are missing.
1 x Stove body
1 x Flue Connector c/w Fireproof Gasket
1 x Firebox Top Baffle Plate
1 x Ash pan & Handle
1 x Grate
1 x Fixings Kit
1 x Heat Resistant Glove
1 x vermiculite plate(2 sides and 1 back
vermiculite plate)
Assembly
Unpack the stove and remove packing materials.Open the door and remove ashpan,
fixing fit from inside the stove.
1. Install the Flue connector upward as picture show below:
If the rear mounting flue configuration is to be used, change the flue connector
backward,then it will be ok.
2. Set ashpan in position as shown picture below. An ashpan handle is supplied for
when the stove is in use.
