PARTS LIST
13
LS-1700/LS-1700HD/TS-1700HD/LS-2000/LS-2000HD/TS-2000HD (03–01)
BASE GROUP
REF PART # DESCRIPTION QTY.
1 140255 SCREW, 1/4–20X1.75 4
2 140016 WASHER, LOCK 4
3 140000 WASHER, FLAT 4
4 602545 BUMPER, 20” MODEL 1
602543 BUMPER, 17” MODEL 1
5 140852 SCREW, SHT MTL #12X3/4 PNPL 2
6 019680127 WASHER, FLAT 2
∇7 130497 MOTOR, 120V 1
Y 130465 COUPLING, MOTOR 1
Y 25516 GEAR BOX 10:1 1
∇7 130451 MOTOR, 120V (1.5 HP) 1
Y 130465 COUPLING, MOTOR 1
Y 25516 GEAR BOX 10:1 1
∇7 130494 MOTOR, 120V DUAL SPEED 1
Y 190742 DCARBON BRUSH CARD ASM. 1
Y 22117 DCARBON BRUSH 4
Y 190753 DRECTIFIER, 120V 1
Y 190744 DCONTROL, SPEED 120V 1
Y 515021 DHOLDER 1
∇7 130488 MOTOR, 230V DUAL SPEED 1
Y 600281 DCARBON BRUSH CARD ASM. 1
Y 190311 DCARBON BRUSH 4
Y 190312 DRECTIFIER, 230V 1
Y 190745 DCONTROL, SPEED 230V 1
∇7 600807 MOTOR, 230V/50HZ 1
Y8 25519 DCAPACITOR, RUN (SILVER) 1
Y
130762 DCAPACITOR, START (BLACK) 1
100058 TAPE, CAPACITOR .17’
9 130198 PLUG 1
10 230858 PLATE, LATCH 1
11 140015 WASHER, LOCK 4
12 140226 SCREW, 5/16–18X.625 4
13 607333 COVER, MOTOR, BLUE 1
14 120582 DECAL, RECESS 1
REF PART # DESCRIPTION QTY.
15 607270 BASE, 17”, BLUE 1
607272 BASE, 20”, BLUE 1
16 608909 AXLE, 1/2X10.040” 1
17 140148 BUSHING 1
18 4252 WASHER, COMP. 4
19 3148.816 WASHER, FLAT 4
20 103064 DWHEEL 2
21 103019 CAP, HUB 2
22 140000 WASHER, FLAT 4
23 140016 WASHER, LOCK 4
24 140255 SCREW, 1/4–20X1.75 4
25 601308 CHOKE (EMC MODEL) 1
26 200160017 NUT, M8 HXLCK (EMC MODEL) 1
27 140062 WASHER, EXT TOOTH 5/16
(EMC MODEL)
1
28 140879 SCREW, 6–32X3/4 RNDSLT
(EMC MODEL)
1
29 601356 BRACKET, RFI FILTER
(EMC MODEL)
1
30 600383 FILTER, RFI LARGE (EMC MODEL) 1
31 600748 DSWITCH, DUAL SPEED
(EMC MODEL)
1
32 130990 DBOOT, RUBBER SWITCH
(EMC MODEL)
1
33 120675 DECAL, SWITCH, DUAL SPEED
(EMC MODEL)
1
∇ ASSEMBLY
Y INCLUDED IN ASSEMBLY
D RECOMMENDED STOCK ITEMS
