PARTS LIST
15
LS-1700/LS-1700HD/TS-1700HD/LS-2000/LS-2000HD/TS-2000HD (03–01)
CONTROL HANDLE GROUP
REF PART # DESCRIPTION QTY.
1 603291 KNOB, PLASTIC 1
2 603112 PIN, HANDLE LOCK 1
3 603105 TRIGGER, HANDLE 2
4 603111 CLIP, SWITCH LEVER 1
5 603108 SPRING, SWITCH 1
6 603109 BRACKET, SWITCH 1
7 140350 SCREW, #10X1/2 2
8 606292 DSWITCH, 20 AMP (120V) 1
603110 DSWITCH, 20 AMP (230V) 1
9 603114 DOWEL 2
10 140401 SPRING, LOCK BUTTON 1
11 130726 DSWITCH, TOGGLE (DUAL SPEED
MODEL)
1
12 140519 NUT, 10–24 KEP 1
13 140324 CLAMP, NYLON 1
14 603292 SCREW, M6X1.0X45 6
15 603102 HOUSING, HANDLE BOTTOM 1
16 578244000 WASHER, LOCK 8
17 140504 NUT, LOCK 1/2” 1
REF PART # DESCRIPTION QTY.
18 140900 SCREW, 10–24X3/4 1
19 578321000 SCREW, M6X1.0X16 2
20 602849 DCORD GRIP (120V) 1
130167 DCORD GRIP (230V) 1
21 602747 POWER CORD, 23M (120V) 1
130275 POWER CORD, 23M (230V) 1
600324 POWER CORD, 230V (DUAL SPEED
MODEL)
1
22 20361 DBREAKER, CIRCUIT 12 AMP (120V) 1
130670 DBREAKER, CIRCUIT 12 AMP (230V) 1
23 130990 DBOOT, SWITCH (DUAL SPEED
MODEL)
1
24 140028 WASHER, 3/8 FLAT 1
25 140946 SCREW, 6–32X1 (EMC MODEL) 2
26 140534 NUT, 6–32 (EMC MODEL) 2
27 130005 STRIP, TERMINAL (EMC MODEL) 1
28 578859 DECAL, GROUND SYMBOL
(EMC MODEL)
1
29 601312 CHOKE (EMC MODEL) 1
D RECOMMENDED STOCK ITEMS
