GB
14
3. POSITIONING AND INSTALLING
The appliance is designed to heat domestic rooms
or similar. It must not be used for other purposes.
The appliance must be used permanently mounted
on a wall as described in the instructions.
Install the
appliance with the thermostat at the bottom (Fig. 2).
In bathrooms (with bath or shower), install the ap-
pliance outside zone 1.
The appliance must be installed in such a way that
the electronic controls and other control devices
may not be touched by someone in the bath or
shower.
The appliance must not be connected
with a plug.
plugs, see the warnings on page 23.
Never install the appliance:
– immediately below or in front of a power socket or
a junction box (Fig. 5)
–
–
or pressure vessels.
Make sure there are no pipes or electric wires in the
wall which could be damaged while mounting the
appliance.
2. GENERAL INFORMATION
Unpack the appliance carefully and rest it on the
polystyrene corner pieces or a carpet.
The package contains:
– the appliance
– mounting kit
– instructions
Read all the instructions carefully before installation
and use. Keep for future consultation.
Install and use the appliance as described in the
se
instructions only.
These instructions do not cover all situations which
might arise. Caution and common sense should be
applied when installing, operating and servicing the
appliance.
Modifying the characteristics of the appliance and
is expressly prohibited. Make sure the appliance is
complete and undamaged. If damaged, do not use
the appliance, but contact your local dealer or a
The materials used for packaging can be recy-
cled. You are therefore recommended to dispose
of them in special differentiated waste collection
containers.
A Brand/Manufacturer
B Model, type, category
C Bidimensional Code (QR)
D Protection class
E CE marking
F Double isolation
G Disposal procedures
H Quality marks
I
Voltage and Power
L Serial number
3.1 WALL MOUNTING
Make sure the screws and anchors included in the
mounting pack are suitable for the type of wall on
which you are mounting the appliance. If in doubt,
Follow the installation sequence shown on the
folding leaf of the cover (Scheme 1), respecting the
minimum distance between the bottom of the ra-
During installation, make sure the power cable is
disconnected from the power line.
-
ed on the rating plate on the side of the radiator (Fig. 1).
1. SPECIFICATIONS OF THE APPLIANCE
Voltage: 230 V ~ 50 Hz
Insulation class: II
Protection class: IPx4
Table 1
The appliance is equipped with a sensor which can
detect an open window, if present above the radia-
tor or within the room. For a proper operation, it
is strongly recommended to comply to the instal-
lation directions reported in Ch. 4.3.2 before wall
mounting.
TYPE
Power
[W]
Length
[cm]
Height
[cm]
Weight
[kg]
Rated current
[A]
CVE0610F
1000 55 58 16 4,5
CVE0915F
1500 79 58 24 6,5
CVE1220F
2000 104 58 32 9
DVE0610F
1000 55 58 11 4,5
DVE0915F
1500 79 58 16 6,5
DVE1118F
1800 95 58 19 8
EVE0610F
1000 55 58 17 4,5
EVE0915F
1500 79 58 25 6,5
EVE1220F
2000 103 58 33 9
FVE0407F
700 39 58 8 3
FVE0610F
1000 55 58 12 4,5
FVE0915F
1500 79 58 18 6,5
FVE1118F
1800 95 58 21 8
