Cata DWIB60 - Aesthetic Panels Dimensions and Installation

18
Minimum space when
the door is opened
【Figure2】
Cabinet dimensions
【Figure1】
Cabinet
Dishwasher
Door of
dishwasher
Minimum space of 50mm
Less than 5mm
between the top
of dishwasher and
cabinet and the
outer door aligned
to cabinet.
90 °
90 °
600 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain a nd
water supply line
entrances
1
The decor door should be fitted in accordance with the measurements detailed in Figure 3.
【Figure
3】
●
Aesthetic panel's dimensions and installation
(Unit: mm)
594
568
254
38
540
15
250
