Note: The safety distance between the ceramic hob and the cupboard
above the hotplate should be at least 750mm.
Air intake
Air exit
Figure (2)
mini 5 cm
mini 5 mm
mini 2 cm
3
Under all circumstances, make sure the ceramic hob is well
ventilated and the air inlet and outlet are not blocked.
Ensure the ceramic hob is in a good work state. As shown in
Figure (2)
2
3 Place
the hob on the table and screw the four brackets to the bottom of hob
(see picture) After installation adjust the bracket position to suit for
different table top thickness.
screw
bracket
base
screw hole
